E5 @ J Temperature Controller Protocol Appendix J
Select Local Mode (Sequence No. 201 (Hex 00C9))
Switches the Controller to local mode.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Select Backup Mode (Sequence No. 202 (Hex 00CA))
Switches from the set point write mode to backup mode.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Select RAM Write Mode (Sequence No. 203 (Hex 00CB))
Switches from set point write mode to RAM write mode.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
First word of
send data
Number of send data words
+0
+1
(Undefined) Unit No.
First word of
send data
Number of send data words+0
+1 (Undefined) Unit No.
First word of
send data
Number of send data words+0
+1 (Undefined) Unit No.
