E5 @ J Temperature Controller Protocol Appendix J
Save Set Point (Sequence No. 204 (Hex 00CC))
Saves the set point.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Parameters 1 (Sequence No. 205 (Hex 00CD))
Writes the set point, alarm value 1, alarm value 2, and a heater burnout alarm value to multiple units.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
First word of
send data
Number of send data words+0
+1 (Undefined) Unit No.
First word of
send data
Number of send data words+0
+1
+2
+3
+4
+5
+6
+122
+123
+124
+125
+126
(Undefined) Unit No.
Set point
~ ~
Alarm value 1
Set point
Alarm value 1
1st unit
25th unit (max.)
Alarm value 2
Heater burnout alarm value
Alarm value 2
Heater burnout alarm value
Number of units
(Undefined) Unit No.
