K3T @ Intelligent Signal Processor Protocol Appendix L
Reset (by Unit Number) (Sequence No. 300 (Hex 012C))
This sequence performs the same processing as when an input is received on the reset terminal.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Reset Control (Continuous Units)
(Sequence No. 301 (Hex 012D))
This sequence performs reset control for continuous units.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits BCD)
0003 to 0022 (3 to 34 decimal)
+1 Number of units
(4 digits Hex)
0001 to 0020 (1 to 32 decimal)
+2 Relevant unit No.
(2 digits BCD)
00 to 99
•
•
•
+33 Relevant unit No.
(2 digits BCD)
00 to 99
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002
+1 Number of units
(4 digits Hex)
0001 to 0020 (1 to 32 decimal)
Relevant unit No.
Number of units
+0
+1
+2
+33
Number of send data wordsFirst word of
send data
~ ~
(Undefined)
Relevant unit No.(Undefined)
Number of units
+0
+1
Number of send data wordsFirst word of
send data
