Omron SYSMAC CJ1W-SCU21-V1 User Manual

608
K3T @ Intelligent Signal Processor Protocol Appendix L
Write Set Value HH with Bank (Continuous Units)
(Sequence No. 308 (Hex 0134))
This sequence writes set value HH of a bank not in use for continuous units.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Set Value H with Bank (Continuous Units)
(Sequence No. 309 (Hex 0135))
This sequence writes set value H of a bank not in use for continuous units. The word allocation is identical to
that of sequence No. 308 (Write Set Value HH with Bank (Continuous Units)).
Write Set Value L with Bank (Continuous Units)
(Sequence No. 310 (Hex 0136))
This sequence writes set value L of a bank not in use for continuous units. The word allocation is identical to
that of sequence No. 308 (Write Set Value HH with Bank (Continuous Units)).
Write Set Value LL with Bank (Continuous Units)
(Sequence No. 311 (Hex 0137))
This sequence writes set value LL of a bank not in use for continuous units. The word allocation is identical to
that of sequence No. 308 (Write Set Value HH with Bank (Continuous Units)).
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0005 to 0062 (5 to 98 decimal)
+1 Number of units
(4 digits Hex)
0001 to 0020 (1 to 32 decimal)
+2 Bank No.
(2 digits BCD)
01 to 04
+3 to +4 Set value
(5 digits BCD)
•
•
•
+96 to
+97
Set value
(5 digits BCD)
Same as above
Bank No.(Undefined)
Number of units
+0
+1
+2
+3
+4
+95
+96
+97
Number of send data wordsFirst word of
send data
~ ~
Bank No.(Undefined)
Set value
(Undefined)
Set value
Set value
(Undefined)
Set value
00000 to 99999
Negative sign: F (5th digit in BCD)
Example 12345
+2
+3
2345
0001
Example –1234
+2
+3
1234
000F
