Omron SYSMAC CJ1W-SCU21-V1 User Manual

609
K3T @ Intelligent Signal Processor Protocol Appendix L
Write Set Value O5 with Bank (Continuous Units)
(Sequence No. 312 (Hex 0138))
This sequence writes set value O5 of a bank not in use for continuous units. The word allocation is identical to
that of sequence No. 308 (Write Set Value HH with Bank (Continuous Units)).
Write Set Value O4 with Bank (Continuous Units)
(Sequence No. 313 (Hex 0139))
This sequence writes set value O4 of a bank not in use for continuous units. The word allocation is identical to
that of sequence No. 308 (Write Set Value HH with Bank (Continuous Units)).
Write Set Value O3 with Bank (Continuous Units)
(Sequence No. 314 (Hex 013A))
This sequence writes set value O3 of a bank not in use for continuous units. The word allocation is identical to
that of sequence No. 308 (Write Set Value HH with Bank (Continuous Units)).
Write Set Value O2 with Bank (Continuous Units)
(Sequence No. 315 (Hex 013B))
This sequence writes set value O2 of a bank not in use for continuous units. The word allocation is identical to
that of sequence No. 308 (Write Set Value HH with Bank (Continuous Units)).
Write Set Value O1 with Bank (Continuous Units)
(Sequence No. 316 (Hex 013C))
This sequence writes set value O1 of a bank not in use for continuous units. The word allocation is identical to
that of sequence No. 308 (Write Set Value HH with Bank (Continuous Units)).
Read Set Value (by Unit Number) (Sequence No. 317 (Hex 013D))
Reads set value HH, H, L, or LL.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0004 to 0042 (4 to 66 decimal)
+1 Number of units
(4 digits Hex)
0001 to 0020 (1 to 32 decimal)
+2 Relevant unit No.
(2 digits BCD)
00 to 99
+3 Operand
(ASCII 2 characters)
4848 (“HH”), 4C4C (“LL”) 4F31 (“01”)
4820 (“H”), 4C20 (“L”) 4F35 (“05”)
Relevant unit No.(Undefined)
Number of units
+0
+1
+2
+3
+64
+65
Number of send data wordsFirst word of
send data
~ ~
Relevant unit No.(Undefined)
Operand
Operand
