Omron SYSMAC CJ1W-SCU21-V1 User Manual

682
Visual Inspection System Protocol Appendix O
Illumination Fluctuation Follow Execution (F300)
(Sequence No. 465 (Hex 01D1))
This sequence executes an illumination fluctuation follow.
Send Data Word Allocation (3rd Operand of PMCR(260))
None.
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Measurement Execution and Positioning (F350)
(Sequence No. 470 (Hex 01D6))
This sequence carries out one measurement and stores the measurement results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
None.
Receive Data Word Allocation (4th Operand of PMCR(260))
Note 1. The number of models that can be stored in a designated word is 1.
2. If a measurement is carried out without executing a camera designation, a measurement is executed
for all cameras in which the measurement model is registered.
3. When the correlation value is less than 70 and the measurement value overflows, the following flags
will be turned ON. The flags for port 1 are CIO 190914 for the Serial Communications Board and CIO
Offset Content (data format) Data
+0 Number of receive data words
(4 digits Hex)
0007
+1 to +2 X displacement (decimal portion)
(3 digits BCD)
X displacement (integer portion)
(3 digits BCD)
X displacement (sign) (1 digit)
(.)
+3 to +4 Y displacement (decimal portion)
(3 digits BCD)
Y displacement (integer portion)
(3 digits BCD)
Y displacement (sign) (1 digit)
(.)
+5 to +6 Correlation value (decimal portion)
(3 digits BCD)
Correlation value (integer portion)
(3 digits BCD)
Correlation value (sign) (1 digit)
(.)
Integer portion
Receive data
storage words
Number of receive data words+0
+1
X displacement
Decimal portion
Sign
+2
+3
Integer portion
Y displacement
Decimal portion
Sign
+4
+5
Integer portion
Correlation value
Decimal portion
Sign
+6
0
Example
–123.456
+1
+2
3456
F012
Example
+123.456
+1
+2
3456
0012
F is stored for negative values.
Example
–123.456
+1
+2
3456
F012
Example
+123.456
+1
+2
3456
0012
F is stored for negative values.
Example
–12.345
+1
+2
2345
F001
Example
+12.345
+1
+2
2345
0001
F is stored for negative values.
