Debug Console Window Section 3-9
83
Registered Condition
Describe the Conditional Equation to register in the I/O
Condition equation. Insert the contents set in the Insert
Equation, insert by Logical Operator button, and paste
from the clip board are possible.
· DEL button Delete the contents of the Con-
ditional Equation.
· or button Insert the character string "or" as
a logical operator.
· and button Insert the character string "and"
as a logical operator.
· Condition
· << button Insert the contents set in the
Insert Equation to the Condi-
tional Equation.
· Delay time Input the delay time (unit: ms) to be registered to the
I/O condition Equation.
Describe the Output Equation to be registered in the
I/O Condition equation.
Insert the contents set in the Insert Equation, insert by
[Operator] button, and paste from the clipboard are
possible.
· DEL button Delete the contents of Output
Equation.
· and button Insert the character string "and"
as a logical operator.
· Output
· << button Insert the contents set in the
Insert Equation.
Insert Equation
· Insert Equation
Select
Select which to insert the Bit Conditional Equation or
the Word Conditional Equation
Set the Bit Conditional Equation to be inserted to the
Conditional/Output Equation.
· Value Select Select which is the value of
Conditional Equation, fixed (up-
per) or I/O memory (lower).
· Type Select I/O memory type.
· Address Input the address of I/O memory
type.
· Operation Select from either = or NOT.
Selecting NOT will not reflect the
value to the Conditional Equa-
tion/Output Equation.
· Bit Conditional
Equation
· Value For "Fixed Value", select
ON/OFF as Bit information in the
drop down list. For "I/O Mem-
ory", set the type and the ad-
dress.
