Debug Console Window Section 3-9
84
Set the Word Conditional Equation to be inserted to
the Conditional Equation/Output Equation.
· Value Selection Select which is the value of
Conditional Equation, fixed (up-
per) or I/O memory (lower).
· Type Select the I/O memory type.
· Address Input the address of I/O memory
type.
· Operator Select =,<>,<=,>=,<,>, or NOT
as an operator from the drop
down list. Selecting NOT will not
reflect the value to the Condi-
tional Equation/Output Equation.
· Word Conditional
Equation
· Value For "Fixed Value", input BCD(0
to 9999) or BIN(0x0 to 0xFFFF).
For "I/O memory", set the type
and the address.
File Menu
· Open Read the I/O Condition file from the File dialog. If
some settings are already input in the window, the
current input data will be discarded.
· Save If the file already opened by Open in the File menu
exists, save the current data to the existing open file. If
a file is not open, this selection is not possible.
· Save As Save the present setting data in the File Save dialog
box.
· Exit Close the Setting window. (Different from Exit of a
tool)
Edit Menu
· line Insert Insert specified number of lines just before the line
currently selected.
· line Delete Delete the specified lines
· line Copy Copy the specified lines to the clipboard. The data on
the clipboard can be used in the commercial spread
sheet software.
· Insert copied lines Insert the data on the clipboard to the currently speci-
fied line. The line data is evaluated when inserting.
Help Menu
· Help Contents Display Help Contents for Windows.
· Help Index Display Help Index for Windows.
· About Display the version information.
