A - 15
Appendices
NX-series Communications Interface Units User’s Manual (W540)
A-3 List of NX Objects
A
A-3-2 NX Objects for the NX-CIF101 and NX-CIF105
• The following table gives the meanings of the set values for the Ch1 Flow Control.
• The following table gives the meanings of the set values for the Ch1 Flow Control Target.
Index
(hex)
Subindex
(hex)
Object name Default Data range Unit
Data
type
Access
I/O allo-
cation
Data
attri-
bute
5006 --- Flow Control --- --- --- --- --- --- ---
01 Ch1 Flow Control 0 0 to 2 --- USINT RW No Y
Set value Description
0 None
1 RS/CS flow control
2 Xon/Xoff control
Index
(hex)
Subindex
(hex)
Object name Default Data range Unit
Data
type
Access
I/O allo-
cation
Data
attri-
bute
5007 --- Flow Control Target --- --- --- --- --- --- ---
01 Ch1 Flow Control
Ta
rget
0 0 to
2 --- USINT RW No Y
Set value Description
0 Transmission and reception
1 Transmission
2 Reception
Index
(hex)
Subindex
(hex)
Object name Default Data range Unit
Data
type
Access
I/O alloca-
tion
Data
attri-
bute
500A --- Number of Characters
to D
etermine the
End
*1
*1. This object is valid when the reception completion condition is set to the number of characters to determine the end.
--- --- --- --- --- --- ---
01 Ch1 Number of Char-
acters to Determine
the End
0 0 to
10,000 0.1
char-
acter
UINT RW No Y
