Omron V1000 Product Information

12 Frequency inverters
Connections for braking resistor
AC reactor
DC reactor
200 V class 400 V class
Max. applicable
motor output kW
Current value
A
Inductance
mH
Max. applicable
motor output kW
Current value
A
Inductance
mH
0.12 2.0 2.0 ------
0.25 2.0 2.0 0.2
1.3 18.0
0.55 2.5 4.2 0.4
1.1 5 2.1 0.75 2.5 8.4
1.5 10 1.1 1.5 5 4.2
2.2 15 0.71 2.2 7.5 3.6
4.0 20 0.53 4.0 10 2.2
5.5 30 0.35 5.5 15 1.42
7.5 40 0.265 7.5 20 1.06
11 60 0.18 11 30 0.7
15 80 0.13 15 40 0.53
200 V class 400 V class
Max. applicable
motor output kW
Current value
A
Inductance
mH
Max. applicable
motor output kW
Current value
A
Inductance
mH
0.12
5.4 8
--------
0.25 0.2
3.2 280.55 0.4
1.1 0.75
1.5
18 3
1.5
5.7 11
2.2 2.2
4.0 4.0 12 6.3
5.5
36 1
5.5
23 3.6
7.5 7.5
11
72 0.5
11
33 1.9
15 15
Power
supply
Thermal
relay
Motor
VZ
Braking resistor
Thermal relay switch for
external braking resistor
Fault contact
MC
SA
SA
SA
MCON
MC
OFFTHRX
THRX
TRX
MC
TRX
FLT-A FLT-B
R/L1
B1 B2
S/L2
T/L3
U/T1
V/T2
W/T3
MCCB
MCCB
Power supply
AC reactor
VZ
R/L1U
V
W
X
Y
Z
S/L2
T/L3
Power
supply
VZ
DC reactor
R/L1
+1 +2
MCCB
S/L2
T/L3

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
