Omron V1000 Product Information

V1000 13
Safety System
R/L1 S/L2 T/L3
S1 S2 S3 S4 S5 S6
−
B1+1+2 B2
U/T1 V/T2 W/T3
24 V
0V
SINK
SOURCE
MA
P1
MB MC
+24 V 8 mA
SC
P2
MP AM AC
PC
IG R
+
R
−
S
+
S
−
H2
RP
+V A1
A2
AC
HC
H1
DC reactor
V1000
Ground
Analog output 0 to +10 VDC (2mA)
Pulse train
output
Terminal resistance (120
Ω
, 1/2 W)
RS-485/422
K1
K2
K1
K1
K2
K2 K1
a
a
+
-
K2
TH
SA
A1 A2
T11 T12
T31 T32
13 23
33 41
14 24
34 42
T21
T22
Control Circuit
Start
Power Supply
Braking resistor
Multi-function digital inputs
MF relay
output
MF
photo-coupler
output
DIP switch S3
Shielded ground terminal
Pulse Input (max. 32kHz) Analog input PS +10.5 VDC, max. 20 mA MF Analog input 1 0 to 10 V (20 kΩ)
MF Analog input 2 0 to 10 V (20 kΩ) or 0/4 to 20 mA (250 Ω)
Safe Disable inputs
V1000 safe stop application using OMRON G9SB safety relay unit complies to safety category 3 according EN 954-1 / Stop category 0 according EN60204 Ensure V1000 and safety relay are mounted in the same cabinet to exclude cross circuit between H1 and H2

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
