Omron V1000 Product Information

2 Frequency inverters
Type designation
200 V class
400 V class
Specifications
Single-phase: VZA@ B0P1 B0P2 B0P4 B0P7 B1P5 B2P2 B4P0
1
1. Only HD settings is available for this model
- - - -
Three-phase: VZA@ 20P1 20P2 20P4 20P7 21P5 22P2 24P0 25P5 27P5 2011 2015
Motor
kW
2
2. Based on a standard 4-pole motor for maximum applicable motor output:
Heavy Duty (HD) mode with a 150% overload capacity
Normal Duty (ND) mode with a 120% overlaod capacity
For HD setting 0.12 0.25 0.4 1.1 1.5 2.2 4.0 5.5 7.5 11 15
For ND setting 0.18 0.37 0.55 1.1 2.2 3.0 5.5
1
7.5 11 15 18.5
Output
characteristics
Inverter capacity kVA
0.3 0.6 1.1 1.9 3.0 4.2 6.7 9.5 13 18 23
Rated output current (A) at HD
0.8 1.6 3.0 5.0 8.0 11.0 17.5 25.0 33.0 47.0 60.0
Rated output current (A) at ND
1.2 1.9 3.5 6.0 9.6 12.0 19.6 30.0 40.0 56.0 69.0
Max. output voltage
Proportional to input voltage: 0..240 V
Max. output frequency
400 Hz
Power
supply
Rated input voltage
and frequency
Single-phase 200..240 V 50/60 Hz
3-phase 200..240 V 50/60 Hz
Allowable voltage
fluctuation
-15%..+10%
Allowable frequency
fluctuation
+5%
Three-phase: VZA@
40P2 40P4 40P7 41P5 42P2 43P0 44P0 45P5 47P5 4011 4015
Motor
kW
1
1. Based on a standard 4-pole motor for maximum applicable motor output:
Heavy Duty (HD) mode with a 150% overload capacity
Normal Duty (ND) mode with a 120% overlaod capacity
For HD setting 0.37 0.55 1.10 1.5 2.2 3.0 4.0 5.5 7.5 11 15
For ND setting 0.37 0.75 1.5 2.2 3.0 4.0 5.5 7.5 11 15 18.5
Output
characteristics
Inverter capacity kVA
0.9 1.4 2.6 3.7 4.2 5.5 7.2 9.2 14.8 18 24
Rated output current (A) at HD
1.2 1.8 3.4 4.8 5.5 7.2 9.2 14.8 18.0 24 31
Rated output current (A) at ND
1.2 2.1 4.1 5.4 6.9 8.8 11.1 17.5 23 31 38
Max. output voltage
0..480V (proportional to input voltage)
Max. output frequency
400 Hz
Power
supply
Rated input voltage
and frequency
3-phase 380..480 VAC, 50/60 Hz
Allowable voltage
fluctuation
-15%..+10%
Allowable frequency
fluctuation
+5%
V1000 series
A: Standard specs
VZAB0P1BAA
Version
Enclosure, Fin, Filter:
B: IP20 without top cover
F: Nema 1
E: IP20 without top cover and C3 filter
Voltage:
B: Single-phase 200 VAC
2: Three-phase 200 VAC
4: Three-phase 400 VAC
Z: European standard
specifications
Coating specs:
A: Standard
[”P” indicates a decimal point]
Max. applicable motor output
0P1: 0.1 kW
~
015: 15 kW

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
