Omron V1000 Product Information

V1000 15
A Line filters
Chokes
B Communication cards
C Accessories
D Computer software
Inverter Line filter Schaffner
Line filter Rasmi
Voltage Model VZA@ Reference Rated current (A) Weight (kg) Reference Rated current (A) Weight (kg)
3-Phase 200 VAC
20P1 / 20P2 / 20P4 / 20P7 A1000-FIV2010-SE 10 0.7 A1000-FIV2010-RE 10 0.8
21P5 / 22P2 A1000-FIV2020-SE 20 0.9 A1000-FIV2020-RE 20 1.1
24P0 A1000-FIV2030-SE 30 1.0 A1000-FIV2030-RE 30 1.3
25P5 / 27P5 A1000-FIV2050-SE
Under development
A1000-FIV2060-RE 58 2.4
2011 A1000-FIV2080-SE A1000-FIV2080-RE 80 -
2015 A1000-FIV2100-SE A1000-FIV2100-RE 100 4.2
Single-Phase 200
VAC
B0P1 / B0P2 / B0P4 A1000-FIV1010-SE 10 0.5 A1000-FIV1010-RE 10 0.6
B0P7 / B1P5 A1000-FIV1020-SE 20 0.7 A1000-FIV1020-RE 20 1.0
B2P2 A1000-FIV1030-SE 30 1.0 A1000-FIV1030-RE 30 1.1
B4P0 A1000-FIV1040-SE 40 1.1 A1000-FIV1040-RE 40 -
3-Phase 400 VAC
40P2 / 40P4 A1000-FIV3005-SE 5 0.5 A1000-FIV3005-RE 5 1.1
40P7 / 41P5 / 42P2 / 43P0 A1000-FIV3010-SE 10 0.75 A1000-FIV3010-RE 10 1.1
44P0 A1000-FIV3020-SE 15 1.0 A1000-FIV3020-RE 20 1.3
45P5 / 47P5 A1000-FIV3030-SE
Under development
A1000-FIV3030-RE 29 2.1
4011 / 4015 A1000-FIV3050-SE A1000-FIV3050-RE 48 2.9
Model Diameter Description
A1000-FEV2102-RE 21
Recommended for motors below 2.2 KW
A1000-FEV2515-RE 25
Recommended for motors below 15 KW
A1000-FEV5045-RE 50
Recommended for motors below 45 KW
Type Model Description Function
Communication
option board
SI-N3/V-OY DeviceNet option card
• Used for running or stopping the inverter, setting or referencing parameters, and monitoring
output frequency, output current, or similar items through DeviceNet communication with the
host controller.
SI-P3/V-OY PROFIBUS-DP option card
• Used for running or stopping the inverter, setting or referencing parameters, and monitoring
output frequency, output current, or similar items through PROFIBUS-DP communication
with the host controller.
SI-S3/V-OY Can open option card
• Used for running or stopping the inverter, setting or referencing parameters, and monitoring
output frequency, output current, or similar items through CANopen communication with the
host controller.
SI-T3/V-OY Mechatrolink II option card
• Used for running or stopping the inverter, setting or referencing parameters, and monitoring
output frequency, output current, or similar items through Mechatrolink II communication with
the host controller.
Types Model Description Functions
Digital
operator
JVOP-180 LCD remote operator LCD Display operator with language support
A1000-CAVOP300-EE Remote operator cable 3 meters cable for connecting remote operator
Accessories
JVOP-181 USB converter / USB cable USB converter unit with copy and backup function
PS-V10S
24 VDC option board
24V DC control board power supply VZA-B/2/4 from 0.1 to 4 KW
PS-V10M 24V DC control board power supply VZA-2/4 from 5.5 to 15 KW
A1000-CAVPC232-EE PC connection cable RS232 PC tool connection cable
Types Model Description Installation
Software
CX-drive Computer software Configuration and monitoring software tool
CX-One Computer software Configuration and monitoring software tool

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
