76
WL-N/WLG
Spatter-prevention Models
* The actuator is identical for the WL and WL-N models.
Connector (Conduit size: JIS B0202G
1
/2)
Note: 1. Please use sealling tape with SC Connectors. SC-1M to SC-5M, however, are provided with an O-ring (NBR) and therefore sealing tape
is not necessary to ensure a proper seal. The SC-6 and SC-P2 models are made of resin. If higher sealing performance is required, use
one of SC-1M to SC-5M, which have metal connectors.
2. Unless otherwise indicated, a tolerance of ±0.4 mm applies to all dimensions.
* mark dimensional table
FA Connectors
Actuator Lever type Indicator Pretravel (PT) Set Model Numbers
Switches without levers Actuator *
Model Model
Roller lever:
R38 mm
Double nut lever
LED
15±5°
WLCA2-LDAS-N WLRCA2-LDS-N
WL-1A105S
Neon lamp WLCA2-LEAS-N WLRCA2-LES-N
LED 10° WLG2-LDAS WLRG2-LDS
Allen-head lever
LED
15±5°
WLCA2-LDS-N WLRCA2-LDS-N
WL-1A103S
Neon lamp WLCA2-LES-N WLRCA2-LES-N
LED 10° WLG2-LDS WLRG2-LDS
Appearance
Dimensions
(Unless otherwise indicated,
a tolerance of ±0.4 mm applies to all dimensions.)
Application/
Specifications
Inner
diameter (D)
of seal
rubber
External diameter
of cable
Model
Applicable
limit switch
models
min. max.
Cabtire cable
(Metal, with
O-ring)
7 dia. 5.5 dia. 7.5 dia. SC-1M
WL@-N
WLG@
Wiring
Specifications:
Screw
terminals
9 dia. 7.5 dia. 9.5 dia. SC-2M
12.5 dia. 11 dia. 13 dia. SC-3M
14 dia. 12 dia. 14 dia. SC-4M
11 dia. 9 dia. 11 dia. SC-5M
Cabtire cable
(Metal)
7 dia. 5.5 dia. 7.5 dia. SC-21
9 dia. 7.5 dia. 9.5 dia. SC-22
12.5 dia. 11 dia. 13 dia. SC-23
14 dia. 12 dia. 14 dia. SC-24
11 dia. 9 dia. 11 dia. SC-25
Cabtire cable
(Resin)
9 dia. 7.5 dia. 9 dia. SC-6
10.6 dia. 8.5 dia. 10.5 dia. SC-P2
Model
Inner diameter (D)
of sealed rubber
Internal
diameter (E) of
washer
Applicable
cable
SC-21, -1M 7 dia. 10.4 dia. 5.5 dia. to 7.5 dia.
SC-22, -2M 9 dia. 13.2 dia. 7.5 dia. to 9.5 dia.
SC-23, -3M 12.5 dia. 14.6 dia. 11 dia. to 13 dia.
SC-24, -4M 14 dia. 14.6 dia. 12 dia. to 14 dia.
SC-25, -5M 11 dia. 13.2 dia. 9 dia. to 11 dia.
SC-6 9 dia. 10 dia. 7.5 dia. to 9 dia.
Model
Number of
conductors
Voltage
specification
Size of conduit
Size of
crimp terminal
Applicable model
SC-2F 2 125 VDC
JIS B0202G1/2 M4
WL-N,
WLG
SC-2FAD 2 250 VDC
SC-4F4D 4 125 VDC
SC-4F4AD 4 250 VDC
+2°
-1°
+2°
-1°
14 dia.
14.6 dia.
30
29.3
*E
15
5
9
(34)
27
JIS B 0202 G
½
*D
Sealing rubber
(nitrile r
ubber)
Connector
(zinc die-cast
and zinc plating)
Washer
(stainless
steel)
Ball head lock nut
(zinc die-cast
and zinc plating)
Sealing rubber
(nitrile rubber)
*D
Sealing rubber
(nitrile r
ubber)
Connector
(brass and
nickel plating)
Washer
(stainless
steel)
Ball head lock nut
(brass and nickel plating)
27.729.3
15
4.8
9
24
14 dia.
14.6 dia.
*E
(34)
JIS B 0202 G
½
22.5
26
9
G
1
½
5
12
9
10
(30.6)
12
9
*D
Sealing rubb
er
(nitrile rubber)
Connector
(polyacetal
resin)
M20×1.5
Washer
(ferrous metal and
zinc plating)
Ball head lock nut
(polyacetal resin)
22
25.4
15
12.6 dia.
10.6 dia.
18 dia.
1 4.5
18 dia.
5
JIS B 0202
G
1
½
Hexagonal nut
(polyacetal resin)
Conduit washer
(ferrous metal
and zinc plating)
Ring
(chloroprene
rubber)
