ZFX-C Serial Communication Command Reference
37
Executing Display Capture to Output an Image < CAPTURE Command >
This command executes display capture.
Captured images are output to the SD card or external devices.
When parameter (mode No.) input is omitted, captured images are output to the SD card.
< Command format >
< File transfer >
When the mode No. is set to 0 and the image is output to external devices, the image data is transferred by
XMODEM (-CRC or SUM) after READY is received. XMODEM (-1k) is not supported.
< Response format >
< Explanation of parameters >
Captured images are transferred to external devices by XMODEM protocol.
Images are sent in bitmap format. Save the images with ".BMP" file extensions.
Mode No. Description
0 Display capture is executed and the captured display is output as an image to external
devices.
1 or omitted Display capture is executed and the captured display is output as an image to SD card.
The captured image is stored to CAPTURE directory in the SD card.
Important
Note
C A PCP
C
R
T U
C
R
R E
or
Mode No.
(0 or 1)
Mode No.
(0 or 1)
OK
C
R
ER
C
R
R EAD
C
R
Y
When processing ends successfully
When processing fails
When Mode No. is set to 0:
OK
C
R
ER
C
R
When processing ends successfully
When processing fails
When Mode No. is set to 1 or omitted:
