ZFX-C Serial Communication Command Reference
Flexible search (available only on ZFX-C20/C25/C10H/C15H)
Sensitive search
Size inspection parameters
Area
Data No. Parameter Output Range
0 Judgment result 0: OK
-1: NG
-2: not measured
1 Correlation 0 to 100
2 Measurement position X -9999.999 to 9999.999
3 Measurement position Y -9999.999 to 9999.999
Data No. Parameter Output Range
0 Judgment result 0: OK
-1: NG
-2: not measured
1 Correlation 0 to 100
2 Measurement position X -9999.999 to 9999.999
3 Measurement position Y -9999.999 to 9999.999
4 Measurement angle -180 to 180
5 Solid color rate 0 to 100
Data No. Parameter Output Range
0 Judgment result 0: OK
-1: NG
-2: not measured
1 Area 0 to 9999999.999
2 Gravity position X -9999.999 to 9999.999
3 Gravity position Y -9999.999 to 9999.999
4 Axis angle -9999.999 to 9999.999
5 Reference area 0 to 9999999.999
6 Reference position X -9999.999 to 9999.999
7 Reference position Y -9999.999 to 9999.999
8 Reference axis angle -180.0 to 180.0
9 Area difference -9999999.999 to 9999999.999
10 Position difference X -9999.999 to 9999.999
11 Position difference Y -9999.999 to 9999.999
12 Axis angle difference -180.0 to 180.0
