About Communication Commands
ZFX-C Serial Communication Command Reference
41
Labeling (available only on ZFX-C20/C25/C10H/C15H)
Data No. Parameter Output Range
0 Judgment result 0: OK
-1: NG
-2: not measured
1 Area 0 to 9999999.999
2 Gravity position X -9999.999 to 9999.999
3 Gravity position Y -9999.999 to 9999.999
4 Number of labels 0 to 65535
5 Axis angle -180.0 to 180.0
6 Perimeter 0 to 9999.999
7 Length X 0 to 9999.999
8 Length Y 0 to 9999.999
9 Roundness 0 to 1.0
10 Reference area 0 to 9999999.999
11 Reference position X -9999.999 to 9999.999
12 Reference position Y -9999.999 to 9999.999
13 Reference axis angle -180.0 to 180.0
14 Reference perimeter 0 to 9999.999
15 Reference length X 0 to 9999.999
16 Reference length Y 0 to 9999.999
17 Reference roundness 0 to 1.0
18 Area difference -9999999.999 to 9999999.999
19 Position difference X -9999.999 to 9999.999
20 Position difference Y -9999.999 to 9999.999
21 Axis angle difference -180.0 to 180.0
22 Perimeter difference -9999.999 to 9999.999
23 Length X difference -9999.999 to 9999.999
24 Length Y difference -9999.999 to 9999.999
25 Roundness difference -1.0 to 1.0
