ZFX-C Serial Communication Command Reference
45
Parameters for inspection by individual application
Grouping (available only on ZFX-C20/C25/C10H/C15H)
Defect
23 Maximum value 0 to 100.0
24 Minimum value 0 to 100.0
Data No. Parameter Output Range
0 Judgment result 0: OK
-1: NG
-2: not measured
1 Correlation 0 to 100
2 Measurement position X -9999.999 to 9999.999
3 Measurement position Y -9999.999 to 9999.999
4 Index No. 0 to 633
Data No. Parameter Output Range
0 Judgment result 0: OK
-1: NG
-2: not measured
1 Defect 0 to 255
2 Maximum density 0 to 255
3 Minimum density 0 to 255
4 Number of defects 0 to 255
5 Defect position X -9999.999 to 9999.999
6 Defect position Y -9999.999 to 9999.999
7 Reference position X -9999.999 to 9999.999
8 Reference position Y -9999.999 to 9999.999
9 Position difference X -9999.999 to 9999.999
10 Position difference Y -9999.999 to 9999.999
Data No. Parameter Output Range
