About Communication Commands
44
ZFX-C Serial Communication Command Reference
Brightness and color inspection parameters
Brightness
Hue
Data No. Parameter Output Range
0 Judgment result 0: OK
-1: NG
-2: not measured
1 Density average 0 to 255.0
2 Density deviation 0 to 127.0
3 Reference density average 0 to 255.0
4 Reference density deviation 0 to 127.0
5 Density average difference 0 to 255.0
6 Density deviation difference 0 to 127.0
Data No. Parameter Output Range
0 Judgment result 0: OK
-1: NG
-2: not measured
1 Hue 0 to 360.0
2 Saturation 0 to 100.0
3 Value 0 to 100.0
4 Hue deviation 0 to 180.0
5 Saturation deviation 0 to 50.0
6 Value deviation 0 to 50.0
7 Reference hue 0 to 360.0
8 Reference saturation 0 to 100.0
9 Reference value 0 to 100.0
10 Hue difference -360.0 to 360.0
11 Saturation difference -100.0 to 100.0
12 Value difference -100.0 to 100.0
13 Reference hue deviation 0 to 180.0
14 Reference saturation deviation 0 to 50.0
15 Reference value deviation 0 to 50.0
16 Hue deviation difference -180.0 to 180.0
17 Saturation deviation difference -50.0 to 50.0
18 Value deviation difference -50.0 to 50.0
19 Maximum hue 0 to 360.0
20 Minimum hue 0 to 360.0
21 Maximum saturation 0 to 100.0
22 Minimum saturation 0 to 100.0
