Omron ZFX-C Command Reference

About Communication Commands
ZFX-C Serial Communication Command Reference
43
Angle (available only on ZFX-C20/C25/C10H/C15H)
4 Maximum pitch 0 to 9999.999
5 Average width 0 to 9999.999
6 Minimum width 0 to 9999.999
7 Maximum width 0 to 9999.999
8 Pitch 1 0 to 9999.999
9 Width 1 0 to 9999.999
10 Pitch 2 0 to 9999.999
11 Width 2 0 to 9999.999
: : 0 to 9999.999
506 Pitch 255 0 to 9999.999
507 Width 255 0 to 9999.999
Data No. Parameter Output Range
0 Judgment result 0: OK
-1: NG
-2: not measured
1 Angle -180.00 to 180.00
2 Edge position X1 -9999.999 to 9999.999
3 Edge position Y1 -9999.999 to 9999.999
4 Edge position X2 -9999.999 to 9999.999
5 Edge position Y2 -9999.999 to 9999.999
6 Reference angle -180.00 to 180.00
7 Reference position X1 -9999.999 to 9999.999
8 Reference position Y1 -9999.999 to 9999.999
9 Reference position X2 -9999.999 to 9999.999
10 Reference position Y2 -9999.999 to 9999.999
11 Angle difference -180.00 to 180.00
12 Position difference X1 -9999.999 to 9999.999
13 Position difference Y1 -9999.999 to 9999.999
14 Position difference X2 -9999.999 to 9999.999
15 Position difference Y2 -9999.999 to 9999.999
Data No. Parameter Output Range
