About Communication Commands
ZFX-C Serial Communication Command Reference
51
Edge inspection parameters
Position
Width
Data No. Parameter Output Range
51 Measurement mode 0:Average, 1: Peak, 2: Bottom
52 Color mode 0: Color filter, 1: Color Pickup
53 Split size 1 to 99
54 Color 0: Light → Dark, 1: Dark → Light
55 Edge level 1 to 99
56 Noise level 0 to 255
57 Noise width 0 to 255
58 Calibration 0: OFF, 1: ON
59 Coordinates mode 0: Normal, 1: Pos. correction
71 X upper limit value -9999.999 to 9999.999
72 X lower limit value -9999.999 to 9999.999
73 Y upper limit value -9999.999 to 9999.999
74 Y lower limit value -9999.999 to 9999.999
Data No. Parameter Output Range
51 Measurement mode 0: Average, 1: Maximum, 2: Minimum
52 Color mode 0: Color filter, 1: Color Pickup
53 Split size 1 to 99
54 Color1 0: Light → Dark, 1: Dark → Light
55 Edge level1 1 to 99
56 Noise level1 0 to 255
57 Noise width1 0 to 255
58 Color2 0: Light → Dark, 1: Dark → Light
59 Edge level2 1 to 99
60 Noise level2 0 to 255
61 Noise width2 0 to 255
62 Calibration 0: OFF, 1: ON
63 Coordinates mode 0: Normal, 1: Pos. correction
71 Edge width upper limit value 0.000 to 9999.999
72 Edge width lower limit value 0.000 to 9999.999
73 Edge position X1 upper limit value -9999.999 to 9999.999
74 Edge position X1 lower limit value -9999.999 to 9999.999
75 Edge position Y1 upper limit value -9999.999 to 9999.999
76 Edge position Y1 lower limit value -9999.999 to 9999.999
77 Edge position X2 upper limit value -9999.999 to 9999.999
78 Edge position X2 lower limit value -9999.999 to 9999.999
79 Edge position Y2 upper limit value -9999.999 to 9999.999
80 Edge position Y2 lower limit value -9999.999 to 9999.999
