About Communication Commands
52
ZFX-C Serial Communication Command Reference
Count
Angle
Data No. Parameter Output Range
51 Search mode 0: Normal, 1: Fine
52 Color mode 0: Color filter, 1: Color Pickup
53 Target color 0: Light, 1: Dark
54 Edge level 1 to 99
55 Noise level 0 to 255
56 Noise width 0 to 255
57 Calibration 0: OFF, 1: ON
71 Number of edges upper limit value 0 to 255
72 Number of edges lower limit value 0 to 255
73 Average pitch upper limit value 0.000 to 9999.999
74 Average pitch lower limit value 0.000 to 9999.999
75 Average width upper limit value 0.000 to 9999.999
76 Average width lower limit value 0.000 to 9999.999
Data No. Parameter Output Range
51 Color mode 0: Color filter, 1: Color Pickup
52 Measurement mode1 0:Average, 1: Peak, 2: Bottom
53 Split size1 1 to 99
54 Color1 0: Light → Dark, 1: Dark → Light
55 Edge level1 1 to 99
56 Noise level1 0 to 255
57 Noise width1 0 to 255
58 Measurement mode2 0:Average, 1: Peak, 2: Bottom
59 Split size2 1 to 99
60 Color2 0: Light → Dark, 1: Dark → Light
61 Edge level2 1 to 99
62 Noise level2 0 to 255
63 Noise width2 0 to 255
64 Calibration 0: OFF, 1: ON
65 Coordinates mode 0: Normal, 1: Pos. correction
71 Angle upper limit value -180.00 to 180.00
72 Angle lower limit value -180.00 to 180.00
73 Region1 X upper limit value -9999.999 to 9999.999
74 Region1 X lower limit value -9999.999 to 9999.999
75 Region1 Y upper limit value -9999.999 to 9999.999
76 Region1 Y lower limit value -9999.999 to 9999.999
77 Region2 X upper limit value -9999.999 to 9999.999
78 Region2 X lower limit value -9999.999 to 9999.999
79 Region2 Y upper limit value -9999.999 to 9999.999
80 Region2 Y lower limit value -9999.999 to 9999.999
