Omtech LYF-20MN - 3 Installation; Overview; Location Selection

10
3.1 Overview
A complete working system consists of the following parts:
• Fiber laser source
• Laser arm with the galvanometer lens
• Computer (not included) with EZCard software
• All applicable connection cables
• Support column
• Working platform
Users can also congure other additional accessories (such as a rotary axis) to suit their needs.
Warning
• Use ONLY the hardware, wiring, and power sources that came with or are compatible with this machine.
Installing equipment that your machine is not designed to work with can lead to poor performance, shortened
service time, increased maintenance costs, property damage, and personal injury.
• Please note the specic requirements of your system's installation. Every customer MUST understand these
notes before installation to execute a proper setup and achieve safe laser performance. If you have any
installation questions or problems, contact our technicians and customer support team.
• Any auxiliary equipment MUST be adjusted to the base machine. Queries may be directed to the dealer or
manufacturer of such equipment.
3.2 Location Selection
Prior to assembling your laser marking machine, select an appropriate location for its use meeting the following
conditions:
• Be sure that it meets all of the requirements discussed in the Safety Information above.
• The location should be stable, level, dry, and climate controlled to ensure an ambient temperature 32–104°F
(0–40°C) and an ambient humidity under 70%.
Warning
The temperature and humidity together should NOT be close to the dew point.
• It is recommended to use a windowless room or to use blinds and/or curtains to avoid exposure to the potential
additional heat of direct sunlight.
• The location should be free of dust and other airborne pollutants and well ventilated enough to process any
fumes produced by the engraving process in accordance with all applicable laws and regulations.
Note: Depending on the materials to be processed, this may require construction of a dedicated ventilation
system.
• It should be away from children; combustible, ammable, explosive, or corrosive materials; and sensitive EMI
machines.
• The power cord should be plugged into a compatible and stable power source via a grounded 3-prong outlet.
Warning
NO other item should be drawing current from the same fuse.
3. Installation
