Omtech LYF-20MN User Manual

3
1.4 Specications
Product Model LYF-20M N LYF-30MN LYF- 50MN
Volt age AC 110–120V~60 Hz AC 110–120V~60 Hz AC 110–120V~60 Hz
Overall Rated Power 600W 600W 600W
Processing Area
9.8×13.4 i n.
250×340 mm
9.8×13.4 i n.
250×340 mm
9.8×13.4 i n.
250×340 mm
Max. Marking Speed
393.7 ips
10000 mm/s
393.7 ips
10000 mm/s
393.7 ips
10000 mm/s
Marking Accuracy 0.01 mm 0.01 mm 0.01 mm
Marking Depth
0.01 in.
0.3 mm
0.01 in.
0.3 mm
0.01 in.
0.3 mm
Field Lens Aperture 110×110 m m 150×150 mm 150×150 mm
Beam Combiner Lens Size
ø
20×2 mm
ø
20×2 mm
ø
20×2 mm
Applicable Rotary Axis Type D50/D60 D50/D60 D50/D60
Laser
Ty pe Fiber Fiber Fiber
Rated Power 20W 30W 50W
Expected Service Life 100,000 hr. 100,000 hr. 100,000 hr.
Wavelength 1064 nm 1064 nm 1064 nm
Modulation Frequency 30–60 kHz 30–60 kHz 30–60 kHz
Pulse Width 100 ns 100 ns 100 ns
Class 4 4 4
Operating Temperature
Range
0–104℉
0–40℃
0–104℉
0–40℃
0–104℉
0–40℃
Required Operating Software EZCad EZCad EZCad
Laser Safety Goggles Protection Level OD 6+ OD 6+ OD 6+
Applicable
Computer
System
EZCad Windows 7/8/10/11
Lightburn (not Included) Windows 7/8/10/11, MacOS
Applicable Image Formats BMP, GIF, JPG, JPEG, DXF, DST, Al, etc.
Dimensions
15.7×13.4×21.3 i n.
40×34×54 cm
15.7×13.4×21.3 i n.
40×34×54 cm
15.7×13.4×21.3 i n.
40×34×54 cm
Net Weight
39.7 lb.
18 kg
39.7 lb.
18 kg
39.7 lb.
18 kg

Omtech LYF-20MN Specifications

General

Brand	Omtech
Model	LYF-20MN
Category	Engraver
Language	English
