12
3. Place the laser arm on the mounting bracket of the support column and
align the holes on the laser arm with the holes on the bracket while
confirming that the scanning head is above the center position of the
processing area.
4. Insert and tighten 4 screws to x the laser arm by using the provided hex
wrench.
5. Connect the machine to the power supply with the provided power cord.
6. Connect the machine to your computer with the provided USB cord.
Note: The computer should not be placed more than 15 feet (4.5 m) away from the laser marking machine in
order to avoid possible interference to the signal in its line.
7. Install the EZCad software to your computer with the provided USB ash drive.
Note:
• See the separate EZCad instruction manual for instructions on installing the software and the requirements
for the computer.
• Familiarize yourself with your software's image design features and laser control settings before beginning
operation of the laser itself.
