Oneida Air Systems Mini-Gorilla - System Specifications; Technical Specifications Overview

1
5
A
M
P
O
U
T
L
E
T
S
N
O
T
F
O
R
U
S
E
W
I
T
H
e Mini-Gorilla requires a 20 Amp outlet receptacle to be installed by a licensed electrician.
6
Oneida Air Systems
System Specications
OPERATION
Fan Rating (with Cyclone & Filter) 583 CFM at 2" SP (990.5 m/hr at 51 mmHO )
Maximum Suction Rating 9" HO (229mmHO)
MOTOR AND ELECTRICAL
Motor Type U.S. Made TEFC Motor
Motor Insulation Class F
Motor Service Factor 1.15
Horsepower 1.5 HP (1.1 kW)
Motor Speed 3,450 RPM
Phase Single-Phase (1ph)
Voltage 110V 220V
Cycle 60Hz
Listed FLA 110v: 16A 220v: 8A
On/O Switch Rocker Switch
Power Cord 15 ft (4.6 m)
Power Connector 110v: NEMA 5-20 / 220v: NEMA 6-20
Recommended Circuit Size 20A
Recommended Circuit Type HACR GFCI
Sound Emission 80.5 dBA @ 10 ft (3m)
IMPELLER
Size 13" (330 mm)
Material Single-piece, backward inclined, non-sparking/non-ferrous
CARTRIDGE FILTER
Filter Media Type G.E. H12 HEPA
Filter Eciency 99.97% @ 0.3 microns
Filter Surface Area 40 Sq. Ft. (3.7 sq m)
SYSTEM DIMENSIONS AND CONSTRUCTION
Barrel/Cyclone Body Molded Static Conductive Resin
Inlet 5" (127 mm) Outer Diameter
Overall Height 64.25" (1,632 mm)
Overall Weight 85 lbs (38.5 kg)
