Onicon F-1110 Owner's Manual

WIRING DIAGRAM
INTERNAL CONNECTIONS FOR
DIVIDED OUTPUT FLOW METERS
MODELS F-1120 / F-1220 / F-1320
SENSING BOARD
DIVIDER BOARD
EXTERNAL CABLE CONNECTIONS
NOTES:
1:1
1:32
1:16
1:8
1:4
1:2
1:4096
1:2048
1:1024
1:512
1:256
1:128
1:64
1:1 JUMPER AT
THIS END
8-22-00
1500 North Belcher Road, Clearwater, Florida 33765 Tel (727) 447-6140 Fax (727) 442-5699
www.onicon.com E-mail: sales@onicon.com
0069-1
AVAILABLE BINARY DIVIDER
SELECTIONS
SELECT ONLY ONE VALUE
OR THE DIVISION WILL
NOT BE CORRECT
TOP TURBINE:
F-1220 ONLY
(WHITE WIRE)
BOTTOM TURBINE:
F-1220 ONLY
(ORANGE WIRE)
(BROWN WIRE)
DIVIDED OUTPUT SWITCH
(BLUE WIRE)
FREQUENCY OUTPUT
(GREEN WIRE)
COMMON GROUND
(BLACK WIRE)
24V AC/DC SUPPLY
(RED WIRE)
EXTERNAL CABLE
NOTE: INTERNAL CONNECTIONS
OMITTED FOR CLARITY
TEST SIGNAL INPUT
1:1 JUMPER AT THIS END
DIVIDER JUMPER BLOCK
BLACK WIRE (BOARD TO BOARD)
GREEN WIRE (BOARD TO BOARD)
RED WIRE (BOARD TO BOARD)
For use with serial numbers
115692 and later
