A d j u s t m e n t M a n u a l I
2
C
Item Low light Adjustment Adj.Process 2AL
3G(UE-DLX)
M o d e l ALL
Measuring
Equipment
Preparation
before Adj.
* Warm up the receiver for more than 30 minutes.
Adjustment 1) Receive the monoscope pattern signal .
Procedure 2) Select either R CUTOFF , G CUTOFF
B CUTOFF in the Service menu.
4) Push 0 key on any mode to make a
horizontal line.
5) Turn the screen knob (the Bottom of FBT)
gradually from fully left to the right &
search for the first appearing colour.
6) Adjust two colours except for the first
colour which appears by the adjustment 5)
to the white colour with the following 1~ 6
key.
7) Turn the screen knob so that a horizontal
line appear slightly.
8) Change the normal screen by pushing 0
key again.
9) Receive the pedestal pattern signal
10) Readjust the Colour of the pattern to white
colour by varying 1~ 6
11
