A d j u s t m e n t M a n u a l
Item Vertical Size Adj. Adj.Process 2AL
3G(UE-DLX)
M o d e l ALL
Measuring
Equipment
Preparation
before Adj.
Adjustment 1) Receive the monoscope pattern signal.
Procedure 2) Select Vertical Size in the Service
menu.
Adjust Vertical Size by varying cursor
left/right keys to get 92% of picture size.
3) When both up & down lines are located
within the 88% ~ 96% range of the
standard lines on the monoscope pattern
signal, it is OK.
18
