Onida 21IQ - Vertical Centering

A d j u s t m e n t M a n u a l I
2
C
Item Vertical Centering Adj.Process 2AL
3G(UE-DLX)
M o d e l ALL
Measuring
Equipment
Preparation
before Adj.
Adjustment 1) Receive the monoscope pattern signal.
Procedure 2) Select Vertical Pos. option in the
Service menu Adjust Vertical Pos using
cursor left/right in such a way that the
centre of monoscope to be the nearest
position of CRT centre line.
