A d j u s t m e n t M a n u a l I
2
C
Item Horizontal Centering Adj.Process 2AL
3G(UE-DLX)
M o d e l ALL
Measuring
Equipment
Preparation
before Adj.
Adjustment 1) Receive the monoscope pattern signal.
Procedure 2) Select H-Center 50 in Service Menu.
3) Adjust it so that H & H’ becomes equal as
shown below . There is a separate H-
centering for AV mode(50 Hz) also.The
same can be adjusted in AV mode
also.
4) Connect the monoscope pattern signal
(60Hz) to Video input terminal.
5) Select H-Center 60 in Service Menu
adjust it so that H & H’ becomes equal as
shown below.
20
