A d j u s t m e n t M a n u a l I
2
C
Item Bright Adjustment Adj.Process 2AL
3G(UE-DLX)
M o d e l ALL
Measuring
Equipment
Preparation
before Adj.
* Warm up the receiver for more than 30 minutes.
* The low light & high light adjustment should be done in
advance.
Adjustment 1) Receive the Black pedestal pattern signal .
Procedure 2) Select Sub Bright in the Service Menu.
3) Adjust the Sub Bright so that the point of
below table gradation value does not shine.
Model Adj.Point
14/20/21" 0%
Note :
While entering in Service Menu ,by default it takes the values of
VSM cartoon, hence the above parameter is adjusted with respect to
cartoon condition.
13
