A d j u s t m e n t M a n u a l I
2
C
Item Colour Tint Adjustment
(NTSC3.58,NTSC4.43)
Adj.Process 2AL
3G(UE-DLX)
M o d e l ALL
Measuring
Equipment
* Oscilloscope
Preparation
before Adj.
* Warm up the receiver for more than 30 minutes.
* Adjust the PICTURE MODE to [DYNAMIC] mode.
Adjustment 1) Connect the NTSC Video Colour bar
pattern signal
Procedure (White 75%) to Video input Terminal.
2) Connect the probe of the oscilloscope to
BLUE CATHODE.
3) Adjust the Sub Tint so that the value
between the white peak and Magenta is
as per the table shown below.
Model Adj.point
(TINT)
14/20/21” +5V
Note: While entering in the SERVICE MENU by default it takes the
value of VSM cartoon ,hence the above parameter is adjusted with
respect to cartoon condition.
16
