6/44 PAGE
PKG
A923 INST SHEET U7(D-AMP TUN) 1 29355523
PKG
A924 INST SHEET CAUTION(COMMON) 1 29355604
PKG
P952 AC CORD AS-UC-2 1 253352ATES
! <MDC> only
PKG
P952 AC CORD AS-CNS 1 253432VOL
! <MDF> only
PKG
P952 AC CORD AS-CCC 1 253358VOL
! <MMR> only
PKG
P952 AC CORD AS-CEE-3 1 253298VOL
! <MMB> only
PKG
P952 or AC CORD AS-UC-2 ( 1) 253297KAW
! <MDC> only
PKG
P953 AC CORD AS-BS 1 253425YUN
! <MMB> only
PKG
P953 or AC CORD AS-BS ( 1) 253425KAW
! <MMB> only
PRINTED CIRCUIT BOARD PARTS LIST A-5VL
NOTE:
! : Safety mark
<MDC>: Canadian model
<MMB>: Britain model
<MDF>: Taiwan model
<MMR>: China model
NSP: Not service part
U008
Power supply PC board BAPS-0270-1A
1B237570-1A <MDC><MDF>
U008
Power supply PC board BAPS-0270-1B
1B237570-1B <MMB>
U008
Power supply PC board BAPS-0270-1D
1B237570-1D <MMR>
U009
Power switch PC board BASW-0271-1A
1B237571-1A <MDC><MDF>
U009
Power switch PC board BASW-0271-1B
1B237571-1B <MMB>
U009
Power switch PC board BASW-0271-1D
1B237571-1D <MMR>
U010 AC inlet terminal PC board BAPS-0272-1A 1B237572-1A <MDC><MDF>
U010 AC inlet terminal PC board BAPS-0272-1B 1B237572-1B <MMB>
U010 AC inlet terminal PC board BAPS-0272-1D 1B237572-1D <MMR>
PCB
CIRCUIT
PART NAME DESCRIPTION Q'TY PART NO. REMARKS
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
