Onkyo A-9010 Service Manual

1/2 PAGE
A-9010(B)WDC
<Note>
Parts marked by "NSP" are generally unavailable because <Notes>
they are not in our Master Spare Parts List. (B) : Black color model
<WDC> : 120V
Canadian/USA/(Mexico) model
: NSP
A-9010(B)WDC
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
Q308 T.R , BIAS KTC3114A 1 HVTKTC3114A
Q408 T.R , BIAS KTC3114A 1 HVTKTC3114A
Q315 T.R , POWER 2SD2390-P 1 HVT2SD2390 !
Q316 T.R , POWER 2SB1560-P 1 HVT2SB1560 !
Q415 T.R , POWER 2SD2390-P 1 HVT2SD2390 !
Q416 T.R , POWER 2SB1560-P 1 HVT2SB1560 !
D901 DIODE , BRIDGE(600V/10A) D10SB60 1 CVDD10SB60 !
[CABINET]
1 KNOB , VOLUME 1 VBN1A289
2 KNOB , BASS 3 VBN1A290
3 KNOB , INPUT 1 VBN1A291
5 BADGE , ONKYO 1 28135317
6 PANEL , FRONT 1 VGW1A567RHZH72
7 BUTTON , POWER 1 VBT1A1211
8 WINDOW , IR 1 VGL1A325
9 INDICATOR , LINE 1 VGL1A326
10 BUTTON , SPEAKER 1 VBT1A1212
11 FOOT 4 VKL1A227
12 CUSHION , FOOT 4 CHG2A289
17 PANEL , REAR 1 VKF1A495Y
19 CABINET , TOP 1 VKC1A233B25
28 TERMINAL , GROUND 1 CMA1A006
29 CORD, POWER(UL, CONNECTOR Type) 1 CJA523FBYA !
31 LABEL , HOT (CAUTION) 1 29392531
32 LABEL , SPEAKER A-9010 1 VQB1A1389Z
33 FUSE(S506 Series, 250V,3.15A) 1 CBA2C3150TLEC !
[TRANS COIL]
30 TRANS , POWER, A-9010 1 CLT5R047ZU !
[TUNER UNIT]
25 A-9010 WDC FRONT PCB ASS'Y * (Parent) 1 COP12710C
25-1 FRONT PCB (Child) 1 COP12710C-1
25-2 INPUT PCB (Child) 1 COP12710C-2
25-3 VOLUME PCB (Child) 1 COP12710C-3
25-4 HEADPHONE PCB (Child) 1 COP12710C-4
25-5 MAIN TRANS 2nd PCB (Child) 1 COP12710C-5
25-6 MAIN TRANS 1st PCB (Child) 1 COP12710C-6
25-7 ETC PCB (Child) 1 COP12710C-7 NSP
25-8 TEMP PCB (Child) 1 COP12710C-8
25-9 POWER PCB (Child) 1 COP12710C-9
26 A-9010 MAIN PCB ASS'Y * (Parent) 1 COP12709C
27 A-9010 DIGITAL PCB ASS'Y * (Parent, 8pcs) 1 COP12711B
A-9010(B)WDC
PACKING PROCEDURES PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[PACKING]
P1 BOX , OUT CARTON A-9010BW DC 1 VPG1A1043X
P2 PAD , RIGHT 1 VPS1A1019
P3 PAD , LEFT 1 VPS1A1020
P4 BAG , POLY (650*600*0.515) (650x600x0.515) 1 29100267
[ACCESSARY]
P5 REMOCON ASS'Y (RC-902S) RC-902S 1 CARTA9010-ON
P6 MANUAL , INSTRUCTION(ENGLISH) 1 VQX1A1897Z
P7 MANUAL , INSTRUCTION 1 VQX1A1898Z
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.

Onkyo A-9010 Specifications

General

Damping factor	95
Amplifier class	-
Frequency range	10 - 100000 Hz
Input sensitivity	150 mV
Audio output channels	2.0 channels
Peak power per channel	44 W
Signal-to-Noise Ratio (SNR)	92 dB
Total Harmonic Distortion (THD)	0.08 %
Purpose	Home
Product color	Black
Connectivity technology	Wired
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	25 W
Package weight	8200 g
Manual	Yes

Weight and Dimensions

Depth	3 mm
Width	435 mm
Height	129.5 mm
Weight	6500 g
