Onkyo A-9050 Service Manual

2/35 PAGE
A015 SCREW 3SMS8W.SW+14B(CU) 5 801634
A016 SCREW 3TTB+8B(3BC) 11 838430088GR
A020 SCREW 4TTC+8C(3BC)SR 4 801658
A050 SCREW 3TTB+8B(3BC) 38 838430088GR
A051 WIRE TIE BSK-1 5 260208
A052 CLAMP HL-38-0 2 27301779
A060 SCREW 3SMS6W.SW+14B(CU) 4 801659
A101 REAR PANEL A-9050 MDC 1 27124465A N
A102 TRM E TERMINAL 1 25060151
A103 CUSHION 2 28141799
A111 SCREW 3TTF+10B(3BC) 2 835430108GR
[CABINET]
A201 F PANEL A-9050(B) 1 27213590A N
A202 BADGE 1 28135317
A203 CLEAR PLT RE(B) 1 28192370A
A204 FACET (3) 3 28200067A
A205 FACET (1) 4 28200066A
A210 F BRACKET (AS)A-9030B 1 27111607B
A211 KNOB (CAP-STBY)B 1 28327091A
A212 KNOB (TONE-VD)B(AS) 3 28327093A
A213 KNOB (INPUT)B(AS) 1 28327095A
A214 KNOB (VOL)B(AS) 1 28327101A N
A215 PLATE (VOL) 1 27262857
A220 SCREW 3TTB+8B(3BC) 17 838430088GR
A221 CLIP CS-1U 1 27255004
A222 TAPE TAPE(CLOTH-8U) 1 29110082
A230 COVER (B) 1 28210114 N
A231 SCREW 3TTB+8B(3BC) 8 838430088GR
A252 CUSHION (BUTYL) 1 28141748
[TRANS COIL]
T901 P TRANS NPT-1625D 1 2302058 N, !
[SW TRM]
F900 FUSE 10A-T/UL-ST2 1 252333GR !
F902 FUSE 10A-T/UL-ST2 1 252333GR !
F951 FUSE 3.15A-UL/T-233 1 252323GR !
F951A LABEL 3.15A/125V 1 29361779
P403 FFC NCFC7-231212 1 2047231212
P7002 FFC NCFC5-071012 1 2045071012
P710 FFC NCFC7-311512 1 2047311512
P901 AC INLET R301X2PSn 1 25053358 !
P901A FASTON AS FASTON SOCKET 1 1F999026A
[MECHA PARTS]

Onkyo A-9050 Specifications

General

Output level	175 mV
Damping factor	60
Amplifier class	A
Output impedance	2200 Ω
Audio output channels	2.0 channels
Peak power per channel	75 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.08 %
AC (power) in	Yes
Audio (L/R) in	5
Audio (L/R) out	1
Digital audio coaxial in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	160 W
Package weight	10500 g

Weight and Dimensions

Depth	330.3 mm
Width	435 mm
Height	139 mm
Weight	820 g
