Onkyo A-9050 Service Manual

3/35 PAGE
A114 CUSHION T5 x 20 x 15HBK 2 28141818
A208 CUSHION HIMELON 3 28141934 N
[TUNER UNIT]
1
U001 U0010, U0011, U0012, U0013, U0014, U0015, U0016, U0017 BAAF-1267-1B * 1 1B280567-1B MDC
U0010 Main PCB AS BAAF-1267-1B 1 1B2805267-1B
U0011 HP Jack PCB AS BAETC-1275-1B 1 1B2805275-1B
U0012 Thermanl Sensor PCB AS BAETC-1278-1B 1 1B2805278-1B
U0013 Power Supply PCB AS BAPS-1280-1B 1 1B2805280-1B
U0014 ETC PCB AS BAETC-1281-1B 1 1B2805281-1B
U0015 Power Supply PCB AS BAPS-1289-1B 1 1B2805289-1B
U0016 ETC PCB AS BAETC-1290-1B 1 1B2805290-1B
U0017 ETC PCB AS BAETC-1298-1B 1 1B2805298-1B
U002 U0020, U0021, U0022, U0023, U0024, U0025 BADIS-1268-1B * 1 1B280568-1B MDC
U0020 Display PCB AS BADIS-1268-1B 1 1B2805268-1B
U0021 Switch PCB AS BASW-1271-1B 1 1B2805271-1B
U0022 Switch PCB AS BASW-1272-1B 1 1B2805272-1B
U0023 ETC PCB AS BAETC-1273-1B 1 1B2805273-1B
U0024 Selector PCB AS BAETC-1274-1B 1 1B2805274-1B
U0025 ETC PCB AS BAETC-1276-1B 1 1B2805276-1B
U003 U0030 BADG-1269-1A *4 1 1B280569-1A MDC
U0030 Digital PCB AS BADG-1269-1A 1 1B2805269-1A
A-9050(B)MDC
PACKING PROCEDURES PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[PACKING]
A017 TAPE TAPE(CLOTH-16U) 1 29110083
A053 TAPE TAPE(CLOTH-8U) 1 29110082
A209 TAPE TAPE(CLOTH-8U) 1 29110082
A301 CARTON A-9050 1 29055371B
A311 PP TAPE W50 SBT-70 1 29110200
A351A UPC LABEL A-9050(B)MDC { 1} 29392043 N
A401 PAD (AS)A-9030 1 29092628B
A401A PAD (L)A-9030 { 1} 29092629B
A401B PAD (R)A-9030 { 1} 29092630B
A451 SHEET 1300 x 650 1 29096147
A452 TAPE (SEROHAN)NITTO NO.29 1 29110149
[ACCESSARY]
A501 WRNTY CARD (ONKYO) 1 29365135

Onkyo A-9050 Specifications

General

Output level	175 mV
Damping factor	60
Amplifier class	A
Output impedance	2200 Ω
Audio output channels	2.0 channels
Peak power per channel	75 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.08 %
AC (power) in	Yes
Audio (L/R) in	5
Audio (L/R) out	1
Digital audio coaxial in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	160 W
Package weight	10500 g

Weight and Dimensions

Depth	330.3 mm
Width	435 mm
Height	139 mm
Weight	820 g
