Onkyo A-9050 Service Manual

4/35 PAGE
A506 REMO CON RC-830S 1 24140830
A507 BATTERY R03/AAA(UM-4) 2 3010124
A507 or BATTERY R03/24D(UM-4) ( 2) 3010503
A701 INS MANUAL En(A-9050) 1 29401270 N
A702 INS MANUAL U2FrEs(A-9050) 1 29401271 N
A711 POLY BAG w250xd350 1 29100250A
A712 TAPE (SEROHAN)NITTO NO.29 1 29110149
P902 AC CORD AS-UC-2 1 253352ATES !
A-9050(B)MDC
PC BOARD PARTS LIST
U001 BAAF-1267-1B
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D300 C-DIODE KDS4148U 1 223283R2
D300 or C-DIODE 1SS352 ( 1) 223234R2
D300 or C-DIODE 1SS355 ( 1) 223269R2
D301 C-DIODE KDS4148U 1 223283R2
D301 or C-DIODE 1SS352 ( 1) 223234R2
D301 or C-DIODE 1SS355 ( 1) 223269R2
D302 ZENER D UDZS7.5B 1 224550750R2
D303 ZENER D UDZS7.5B 1 224550750R2
D304 C-DIODE KDS4148U 1 223283R2
D304 or C-DIODE 1SS352 ( 1) 223234R2
D304 or C-DIODE 1SS355 ( 1) 223269R2
D315 C-DIODE KDS4148U 1 223283R2
D315 or C-DIODE 1SS352 ( 1) 223234R2
D315 or C-DIODE 1SS355 ( 1) 223269R2
D316 C-DIODE KDS4148U 1 223283R2
D316 or C-DIODE 1SS352 ( 1) 223234R2
D316 or C-DIODE 1SS355 ( 1) 223269R2
D317 C-DIODE KDS4148U 1 223283R2
D317 or C-DIODE 1SS352 ( 1) 223234R2
D317 or C-DIODE 1SS355 ( 1) 223269R2
D322 DIODE RL1N4003 1 22380260T
D323 DIODE RL1N4003 1 22380260T
D324 DIODE RL1N4003 1 22380260T
D325 C-DIODE KDS4148U 1 223283R2
D325 or C-DIODE 1SS352 ( 1) 223234R2

Onkyo A-9050 Specifications

General

Output level	175 mV
Damping factor	60
Amplifier class	A
Output impedance	2200 Ω
Audio output channels	2.0 channels
Peak power per channel	75 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.08 %
AC (power) in	Yes
Audio (L/R) in	5
Audio (L/R) out	1
Digital audio coaxial in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	160 W
Package weight	10500 g

Weight and Dimensions

Depth	330.3 mm
Width	435 mm
Height	139 mm
Weight	820 g
