Onkyo A-9050 Service Manual

5/35 PAGE
D325 or C-DIODE 1SS355 ( 1) 223269R2
D380 C-DIODE S1NB60-4062 1 22380318R2
D501 ZENER D UDZS5.6B 1 224550560R2
D502 ZENER D UDZS5.6B 1 224550560R2
D503 C-DIODE KDS4148U 1 223283R2
D503 or C-DIODE 1SS352 ( 1) 223234R2
D503 or C-DIODE 1SS355 ( 1) 223269R2
D504 C-DIODE KDS4148U 1 223283R2
D504 or C-DIODE 1SS352 ( 1) 223234R2
D504 or C-DIODE 1SS355 ( 1) 223269R2
D510 C-DIODE KDS4148U 1 223283R2
D510 or C-DIODE 1SS352 ( 1) 223234R2
D510 or C-DIODE 1SS355 ( 1) 223269R2
D511 C-DIODE KDS4148U 1 223283R2
D511 or C-DIODE 1SS352 ( 1) 223234R2
D511 or C-DIODE 1SS355 ( 1) 223269R2
D512 ZENER D UDZS3.3B 1 224550330R2
D513 ZENER D UDZS3.3B 1 224550330R2
D520 C-DIODE KDS4148U 1 223283R2
D520 or C-DIODE 1SS352 ( 1) 223234R2
D520 or C-DIODE 1SS355 ( 1) 223269R2
D521 C-DIODE KDS4148U 1 223283R2
D521 or C-DIODE 1SS352 ( 1) 223234R2
D521 or C-DIODE 1SS355 ( 1) 223269R2
D901 C-DIODE S1NB60-4062 1 22380318R2
D902 C-DIODE KDS4148U 1 223283R2
D902 or C-DIODE 1SS352 ( 1) 223234R2
D902 or C-DIODE 1SS355 ( 1) 223269R2
D951 C-DIODE S1NB60-4062 1 22380318R2
D952 C-DIODE KDS4148U 1 223283R2
D952 or C-DIODE 1SS352 ( 1) 223234R2
D952 or C-DIODE 1SS355 ( 1) 223269R2
D953 C-DIODE KDS4148U 1 223283R2
D953 or C-DIODE 1SS352 ( 1) 223234R2
D953 or C-DIODE 1SS355 ( 1) 223269R2
D954 ZENER D UDZS5.1B 1 224550510R2
D955 C-DIODE KDS4148U 1 223283R2
D955 or C-DIODE 1SS352 ( 1) 223234R2
D955 or C-DIODE 1SS355 ( 1) 223269R2
Q300 IC R2S15211FP 1 22242297R3
Q301 TR RTAN430C-T112-1 1 2217780R2
Q301 or TR RN1441 ( 1) 2215410R2

Onkyo A-9050 Specifications

General

Output level	175 mV
Damping factor	60
Amplifier class	A
Output impedance	2200 Ω
Audio output channels	2.0 channels
Peak power per channel	75 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.08 %
AC (power) in	Yes
Audio (L/R) in	5
Audio (L/R) out	1
Digital audio coaxial in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	160 W
Package weight	10500 g

Weight and Dimensions

Depth	330.3 mm
Width	435 mm
Height	139 mm
Weight	820 g
