Onkyo A-9050 Service Manual

6/35 PAGE
Q302 TR RTAN430C-T112-1 1 2217780R2
Q302 or TR RN1441 ( 1) 2215410R2
Q303 TR RTAN430C-T112-1 1 2217780R2
Q303 or TR RN1441 ( 1) 2215410R2
Q304 TR RTAN430C-T112-1 1 2217780R2
Q304 or TR RN1441 ( 1) 2215410R2
Q305 IC 79M12HF(NJM79M12FA) 1 222790125JRC
Q306 IC 78M12HF(NJM78M12FA) 1 222780125JRC
Q306A HEAT SINK RAD-231 1 27160592
Q306B SCREW 3P+6FN(3BC) 2 82143006GR
Q315 TR 2SC3324-GR(TE85L_F) 1 2216825R2
Q316 TR 2SC3324-GR(TE85L_F) 1 2216825R2
Q317 TR 2SA1312-GR(TE85L_F) 1 2216835R2
Q318 TR 2SA1312-GR(TE85L_F) 1 2216835R2
Q319 TR 2SC3324-GR(TE85L_F) 1 2216825R2
Q320 TR 2SC3324-GR(TE85L_F) 1 2216825R2
Q321 IC NJM4580M-D 1 22241448R2
Q322 TR RTAN430C-T112-1 1 2217780R2
Q322 or TR RN1441 ( 1) 2215410R2
Q325 IC NJM4580M-D 1 22241448R2
Q340 TR KRC105S 1 2217290R2
Q4100 IC LM61CIZ 1 22242212
Q4100A RETAINER (PTH) 1 27141884-1
Q501 TR 2SC3324-BL 1 2216826R2
Q502 TR 2SC3324-BL 1 2216826R2
Q503 TR 2SC3324-BL 1 2216826R2
Q504 TR 2SC3324-BL 1 2216826R2
Q505 TR 2SC3324-BL 1 2216826R2
Q506 TR 2SC3324-BL 1 2216826R2
Q507 TR 2SA949-Y(TPE6_F) 1 2211354T
Q507 or TR 2SA949-O(TPE6_F) ( 1) 2211353T
Q508 TR 2SA949-Y(TPE6_F) 1 2211354T
Q508 or TR 2SA949-O(TPE6_F) ( 1) 2211353T
Q509 TR 2SA949-Y(TPE6_F) 1 2211354T
Q509 or TR 2SA949-O(TPE6_F) ( 1) 2211353T
Q510 TR 2SA949-Y(TPE6_F) 1 2211354T
Q510 or TR 2SA949-O(TPE6_F) ( 1) 2211353T
Q511 TR 2SA949-Y(TPE6_F) 1 2211354T
Q511 or TR 2SA949-O(TPE6_F) ( 1) 2211353T
Q512 TR 2SA949-Y(TPE6_F) 1 2211354T
Q512 or TR 2SA949-O(TPE6_F) ( 1) 2211353T
Q513 TR 2SC2229-Y(TPE6_F) 1 2211634T

Onkyo A-9050 Specifications

General

Output level	175 mV
Damping factor	60
Amplifier class	A
Output impedance	2200 Ω
Audio output channels	2.0 channels
Peak power per channel	75 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.08 %
AC (power) in	Yes
Audio (L/R) in	5
Audio (L/R) out	1
Digital audio coaxial in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	160 W
Package weight	10500 g

Weight and Dimensions

Depth	330.3 mm
Width	435 mm
Height	139 mm
Weight	820 g
