Onkyo A-9050 Service Manual

7/35 PAGE
Q513 or TR 2SC2229-O(TPE6_F) ( 1) 2211633T
Q514 TR 2SC2229-Y(TPE6_F) 1 2211634T
Q514 or TR 2SC2229-O(TPE6_F) ( 1) 2211633T
Q515 TR KTC3198-GR 1 2215985T
Q516 TR KTC3198-GR 1 2215985T
Q517 TR KTC3198-GR 1 2215985T
Q518 TR KTC3198-GR 1 2215985T
Q519 TR 2SC2229-Y(TPE6_F) 1 2211634T
Q519 or TR 2SC2229-O(TPE6_F) ( 1) 2211633T
Q520 TR 2SC2229-Y(TPE6_F) 1 2211634T
Q520 or TR 2SC2229-O(TPE6_F) ( 1) 2211633T
Q521 TR 2SA949-Y(TPE6_F) 1 2211354T
Q521 or TR 2SA949-O(TPE6_F) ( 1) 2211353T
Q522 TR 2SA949-Y(TPE6_F) 1 2211354T
Q522 or TR 2SA949-O(TPE6_F) ( 1) 2211353T
Q531 TR 2SC2229-Y(TPE6_F) 1 2211634T
Q531 or TR 2SC2229-O(TPE6_F) ( 1) 2211633T
Q532 TR 2SC2229-Y(TPE6_F) 1 2211634T
Q532 or TR 2SC2229-O(TPE6_F) ( 1) 2211633T
Q533 TR KTA1266-GR 1 2215975T
Q534 TR KTA1266-GR 1 2215975T
Q550 TR 2SA1163-BL(TE85L_F) 1 2216756R2
Q550 or TR KTA1517-GR ( 1) 2216305R2
Q550 or TR KTA1517-BL ( 1) 2216306R2
Q551 TR 2SA1163-BL(TE85L_F) 1 2216756R2
Q551 or TR KTA1517-GR ( 1) 2216305R2
Q551 or TR KTA1517-BL ( 1) 2216306R2
Q552 TR 2SC2712-GR 1 2213145R2
Q552 or TR KTC3875-GR ( 1) 2216175R2
Q553 TR 2SC2712-GR 1 2213145R2
Q553 or TR KTC3875-GR ( 1) 2216175R2
Q560 TR KRC105S 1 2217290R2
Q560 or TR RN1405 ( 1) 2214500R2
Q560 or TR DTC123JKA ( 1) 2216690R2
Q561 TR KRC105S 1 2217290R2
Q561 or TR RN1405 ( 1) 2214500R2
Q561 or TR DTC123JKA ( 1) 2216690R2
Q900 TR KRC105S 1 2217290R2
Q900 or TR RN1405 ( 1) 2214500R2
Q900 or TR DTC123JKA ( 1) 2216690R2
Q951 IC S-80127CNMC-JKM-T2 1 22241642R2
Q952 TR KRC105S 1 2217290R2

Onkyo A-9050 Specifications

General

Output level	175 mV
Damping factor	60
Amplifier class	A
Output impedance	2200 Ω
Audio output channels	2.0 channels
Peak power per channel	75 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.08 %
AC (power) in	Yes
Audio (L/R) in	5
Audio (L/R) out	1
Digital audio coaxial in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	160 W
Package weight	10500 g

Weight and Dimensions

Depth	330.3 mm
Width	435 mm
Height	139 mm
Weight	820 g
