Onkyo A-9377 Service Manual

3/4 PAGE
EXPLODED
A37 COVER A9377(B)(ONKYO) PC 770F BLACK t0.5 A3/SAFETY 1 4310214912100S (B)
EXPLODED
A37 COVER A9377(S) PC G42 CLEAR t0.5 A3/SAFETY 1 4310214912000S (S)
EXPLODED
A38 COVER AVR1908 SRE2(DENON) 94HB.BLACK POM A4/HOLDER 6 4310213701000S (B)
EXPLODED
A38 COVER AVR1909SPE2(DENON) (DENON)SP POM A4/HOLDER 6 4310213701100S (S)
EXPLODED
A39 COVER A9377 PC-770F BLACK t0.5 A4/SCREW 2 4310214932000S
EXPLODED
A40 FELT
A9377 10X30Xt0.25 부직포 A4/SIDE
2 2690210269000S
EXPLODED
A41 SPRING
VSAS1/JJXCN(PIONEER) SWP PI1.2 내경PI7.7 A4/KNOB
2 3720210276000S
EXPLODED
A50 RIVET () SNAP RIVET DASR-355 8 1560040036010S
EXPLODED
E01 WIRE TIE BSK-1 6 260208 ALL
EXPLODED
E02 WIRE TIE BSK-1 1 260208 <CWT>
EXPLODED
(U01) P.C.B TOTAL ASSY A9377/CPP(ONKYO) / MAIN* 1 7025HA0802020 <CPP>
EXPLODED
(U01) P.C.B TOTAL ASSY A9377/CWT(ONKYO) / MAIN* 1 7025HA0802010 <CWT>
EXPLODED
U01-1 P.C.B SUB ASSY A9377/CPP(ONKYO) / MAIN (1) 7028068111010
EXPLODED
U01-2 P.C.B SUB ASSY A9377/CPP(ONKYO) / POWER (1) 7028068112020 <CPP>
EXPLODED
U01-2 P.C.B SUB ASSY A9377/CPP(ONKYO) / POWER (1) 7028068112010 <CWT>
EXPLODED
U01-3 P.C.B SUB ASSY A9377/CPP(ONKYO) / VOL_SEL (1) 7028068113010 <CWT>
EXPLODED
(U02) P.C.B TOTAL ASSY A9377/CPP(ONKYO) / FRONT* 1 7025HA0802021 <CPP>
EXPLODED
(U02) P.C.B TOTAL ASSY A9377/CWT(ONKYO) / FRONT* 1 7025HA0802011 <CWT>
EXPLODED
U02-1 P.C.B SUB ASSY A9377/CPP(ONKYO) / FRONT (1) 7028068121010
EXPLODED
U02-2 P.C.B SUB ASSY A9377/CPP(ONKYO) / REMOTE (1) 7028068122010
EXPLODED
U02-3 P.C.B SUB ASSY A9377/CPP(ONKYO) / POWER_S/W (1) 7028068123010
EXPLODED
U02-4 P.C.B SUB ASSY A9377/CPP(ONKYO) / H_P (1) 7028068124010
EXPLODED
U02-5 P.C.B SUB ASSY A9377/CPP(ONKYO) / VOLUME (1) 7028068125010
A-9377
PACKING PROCEDURE PARTS LIS
T
<Notes>
(B) : Black model
(S) : Silver model
<CPP> : European model

Onkyo A-9377 Specifications

General

Package depth	549 mm
Package width	428 mm
Package height	258 mm
Dimensions (WxDxH)	435 x 15 x 348 mm
Power requirements	AC 220-230 V, 50/60 Hz
Impedance	4 Ω
Frequency range	10 - 70000 Hz
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.08 %
Product color	Silver
Package weight	10700 g
Power consumption (typical)	286 W

Weight and Dimensions

Weight	8800 g
