Onkyo CS-375D User Manual

> Before Start > Part Names > Install > Playback
Advanced Setup | Others
14
USB Memory
You can play MP3 music files by connecting a USB
memory to the USB port on the front of the unit.
0 The supported sampling rates for MP3 files are 32
kHz to 48 kHz, and supported bitrates are between
32 kbps and 320 kbps and VBR.
Basic operations
Perform the following procedure when the unit is on.
1. Repeatedly press INPUT 2/1 on the remote
controller to switch input to USB.
2. Plug your USB memory into the USB port on the
front.
3. After reading is complete, use 3/4 (d) on the
remote controller to select the folder or file. If you
selected a folder, the content of the folder is
displayed when you press ENTER (f). To return to
the previous display, press (c).
When you select a file and press ENTER (f) on the
remote controller, play starts.
0 Only the music files in the same level of the folder
are played.
4. Use play buttons (e) to stop play or choose tracks to
play. You can also select by entering the track
number with number buttons (a) and pressing
ENTER (f).
Also, by pressing (b), you can switch the display
in the order Track title/Artist name/Album name/
Track number in the folder, Elapsed play time/
Remaining play time.
0 ID3 version 1 (1.0 and 1.1) only is supported with
the title, artist name, and album name displays.
0 Characters that cannot be displayed by this unit
appear as "
∫ ".
0 A maximum of 255 folders and 999 files can be
read. This includes folders that contain files this
unit cannot play.
1
2
f
h
b
d
g
a
c
e
e

Onkyo CS-375D Specifications

General

Coloration	Monochromatic
DAB antenna	Yes
Bluetooth profiles	A2DP, AVRCP
DAB III band range	174.928 - 239.2 MHz
Type	-
Cassette deck	No
Product color	Black
Number of optical discs	1 discs
Impedance	6 Ω
Speaker type	2-way
Frequency range	55 - 40000 Hz
RMS rated power	40 W
Woofer diameter	130 mm
Tweeter diameter	25 mm
Number of speakers	2
Signal-to-Noise Ratio (SNR)	90 dB
Total Harmonic Distortion (THD)	0.05 %
Power source	AC
Input voltage	220 - 240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Tuner type	Digital
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	40
Bluetooth version	4.1
Headphone outputs	1
Headphone connectivity	3.5 mm
Playback modes	Normal, Random, Repeat
Disc types supported	CD, CD-R, CD-RW
Playback disc formats	CD audio

Weight and Dimensions

Package type	Box
Package depth	464 mm
Package width	348 mm
Package height	250 mm
Package weight	9100 g
Main unit weight	2200 g
Main unit dimensions (WxDxH)	215 x 296.5 x 117 mm
