EXPLODED VIEW PARTS LIST OF DVD MECHANISM DR-C500
[NOTE]
REF NO. PART NAME DESCRIPTION
PARTS NO.
REMARK
Z1: DWG ASSY CAROUSEL
M1 SCREW-ST 3 x 10 BLACK
20692310
M2 PLATTER TC5E
10746630
M3 SCREW-ST 3 x 8
20349380
M4 SUPPORT DRAWER
10746590
Z5 DWG ASY DRAWER TC5E
10767370
Z6 DWG ASY BASE TC5E
10767360
M7 SCREW WASHER
10520320
M8 CUSHON 8
10741230
M9 DVD MODULE TVM503R6
10779450
M10 BRACKET TC5E
10746530
M11 SCREW SPEC 3 x 10
10752960
Z5: DWG ASSY DRAWER
The parts which constitute DWG ASSY DRAWER.
M21
PUCK LOAD
10745820
M22 YOKE PUCK LOAD 10698670
M23 SCREW ST 3 x 8 20349380
M24 HOLDER PUCK DVD TC5E 10746580
M25 CAM LIFTER TC5E 10746550
M26 SCREW ST 3 x 10 20692300
M27 GEAR MAIN TC5E 10746540
M28 COVER GEAR TC5E 10746560
M29 RUBBER BELT DRIVE 55073350
M30 GEAR PULLEY 10707950
M31 GEAR DRIVE 10707940
M32 SCREW 2.6 x 4 20349530
M33 BASE TC5E 10746520
M34 RUBBER SPACER 20689440
M35 MOTOR ASSY DC ---
Z6: DWG ASY BASE
The parts which constitute DWG ASSY BASE
M41 RUBBER ROLLER
20712120
M42 ROLLER HUB
10707920
M43 COVER DRAWER
10746650
M44 MOTOR ASSY LOADING
---
M46 GEAR PLATTER
10746640
M47 DRAWER
10746620
M48 SCREW 1.7 x 3
10703470
M49 ASY PCB SENSOR
10658770
M50 GEAR PULLEY
10707950
M51 RUBBER BELT DRIVE
55073350
