Onkyo DR-C500 User Manual

EXPLODED VIEW PARTS LIST
[NOTE]
B: BLACK MODEL ONLY
S: SILVER MODEL ONLY
REF NO. PART NAME DESCRIPTION
PARTS NO.
50 FRONT PANEL, BLACK BLACK
55465620
50 FRONT PANEL, SLVER SILVER
55466820
60 FACET, STANDBY STANDBY
55186710
70 KNOB BASE, DISC NUMBER 5KEY
55464220
80 HOLDER, ILLUMINATION
55464520
90 KNOB BASE, STANDBY/ON 1KEY
55464420
100 KNOB BASE, PLAY 3KEY
55464120
110 KNOB BASE, INPUT BLACK 6KEY
55464320
110 KNOB BASE, INPUT SILVER
55466920
120 KNOB CAP, INPUT-A
55464720
130 KNOB CAP, INPUT-B
55464820
140 KNOB CAP, OPEN
55464920
150 KNOB CAP, PLAY
55465020
160 KNOB CAP, STOP
55465220
170 KNOB CAP, STANDBY
55465120
180 KNOB CAP, DISC NUMBER
55483350
190 FACET ILLUMINATION
55465420
200 CLEAR PLATE
55465720
210 DOOR TRAY, BLACK
55465320
210 DOOR TRAY, SILVER
55467720
220 KNOB, MASTER VOLUME, BLACK
55465520
220 KNOB, MASTER VOLUME, SILVER
55467020
230 CHASSIS
55466120
240 TOP COVER, BLACK
5546672A
240 TOP COVER, SILVER
5546752A
250 REAR PANEL
5546652A
260 BRACKET, FRONT
55466020
270 BRACKET, MAIN
55466320
280 BRACKET, AMP
55466220
290 HEATSINK
55466420
300 BRACKET, MPEG PCBA
55465820
310 BRACKET, MPEG PCBB
55465920
320 POWER SUPPLY CORD 0.75mm2 2200mm BK US LMPS0242-0
55190780
330 BUSHING #2271
27300750
350 TAPPING SCREW 3TTB+8B
838130088
360 TAPPING SCREW 3TTB+6B 838130068
370 SPECIAL SCREW 4 x 8 4mm x 8mm ROUND END TYPE
55215980
380 TAPPING SCREW 3TTW+8B
55127120
400 TUNER UNIT KST-MB011MA0-70 OEM US/
55451470
410 PLATE, BOTTOM
55477040
470 LEG ROUND 12.5mm 50mm
55125120
480 LEG RUBBER 3.0mm 25.0mm JIS 60 Y DIA
55141370
510 POWER TRANSFORMER, 120V 120V
55506070
520 POWER SUPPLY UNIT
55506080
540 SCREW 3MM 6MM MACHINE 3mm x 6mm
55164810
550 MACHINE SCREW 3 x 14 3mm x 14mm
20349160
TAPPING SCREW, 3 x 6 BLACK
55546030
TAPPING SCREW, 3 x 6 SILVER 3mm x 6mm SILVER
55546020
565 TAPPING SCREW, 3 x 10 BLACK 3mm x 10mm BLACK
55135460
570 TAPPING SCREW 3 x 6 3mm x 6mm ROUND END TYPE
55552700
580 WASHER 3 - 8 -0.5 3.0mm - 8.0mm -0.5mm N/A 00 0 0
20523540
590 GUIDE, CNT
55552680
610 CORE 34.5 x 21 x 12 K-150
55148840
620 SHIELD PLATE 71TSFK-13-0.6-20-13
55588060
630 CUSHION AC 15 x 15 x 15
55598150
640 CUSHION 99 x 10 x 0.5
55584250
650 PLATE 30 x 8 x 1.0 (PC-1.0T)
55602400
660 PLATE 38 x 120 x 0.3T BK NON-METAL
55190770
250 CUSHION FL 20mm x 12mm x 5mm
55468440
670 SHIELD PLATE, SPEAKER
55466620
M DVD MECHANISM KIT 5E/TVM503R6
10784020
U1 MECHA CONTROL PC BOARD ASSY
55463320
U2 FRONT PC BOARD ASSY
55461520
U5 POWER SUPPLY PC BOARD ASSY
55461620
U6 MPEG PC BOARD ASSY
55469560
U7 MAIN PC BOARD ASSY
55461720
U8 DIGITAL AMPLIFIER ASSY
55461820
P109 FLAT CABLE 13P110 13pin 1.25mm Pitch 110mm Shield type
55550820NR
P110 FLAT CABLE 21P\50 21pin 1.25mm Pitch 50mm
55489290NR
P21 FLAT CABLE 19P350 19pin 1.25mm Pitch 350mm Shield type
55550810NR
P106 FLAT CABLE 25P250 25pin 1.25mm Pitch 250mm
55489250NR
P107 FLAT CABLE 29P250 29pin 1.25mm Pitch 250mm Shield type
55590850NR
P100 WIER SOCKET ASSY 2P 200mm
55553910NR
F901 FUSE 6.3A/250V DETIMELG
55126930
F101 FUSE 3A/125V SLWBL
55639760
