Onkyo DR-C500 - Pc Board Parts List

1/8 PAGE
PC BOARD PARTS LIST DR-C500
[NOTES]
U1
U1 MECHANISM CONTROL PC BOARD
U1 REF NO. NAME DESCRIPTION PART NO.
NOTES
U1 C001 CERA C 22P0F+5%-5%50V 80434590
U1 C002 CERA C 100N0F+80%-20%25V 20246470
U1 C003 CERA C 100N0F+80%-20%25V 20246470
U1 C004 CERA C 100N0F+80%-20%25V 20246470
U1 C005 ELECT C 1MI0F+20%16V 55475030
U1 P001 CONNECTOR AS 12P550MMUL1007 55553930
U1 P002 CONNECTOR AS 2P150MMUL1007 55183500
U1 P026 PLUG WAFER 2MM6MARNAT 55123400
U1 D001 ZENER D 1N5232B5.6V 20414280
U1 D002 ZENER D 1N5232B5.6V 20414280
U1 PI01 OPT PARTS D-PHOTOITR9606 20586840
SENSOR
U1 PI02 OPT PARTS D-PHOTOITR9606 20586840
SENSOR
U1 IC01 IC BA6209N 20458950
U1 IC02 IC BA6209N 20458950
U1 L001 COIL LF39U0H+10% 20265120
U1 P001 SOCKET AS 12PIN 550M 55553930NR
U2
U2 FRONT PC BORAD
U2 REF NO. NAME DESCRIPTION PART NO.
NOTES
U2 C704 ELECT C CE47U0F+20%16V 20342060
U2 C706 ELECT C CE1U0F+20%50V 20251830
U2 D701 CHIP D 1SS355 20496510
U2 D703 CHIP D 1SS355 20496510
U2 D704 ZENER D UDZS5.1B 55177710
U2 D705 ZENER D UDZS5.1B 55177710
U2 D706 ZENER D UDZS5.1B 55177710
U2 D708 LED LTL-42CB6NBU 55136330 BLUE
U2 D709 LED LTL-1CHPEB-RD 55129160 RED
U2 D710 LED LTL-1CHGECP-GN 55179290 GREEN
U2 D711 LED LTL-1CHGECP-GN 55179290 GREEN
U2 D712 LED LTL-1CHGECP-GN 55179290 GREEN
U2 D713 LED LTL-1CHGECP-GN 55179290 GREEN
U2 D714 LED LTL-1CHGECP-GN 55179290 GREEN
U2 DP70 FL TUBE DISPLAYHNV-12MM33 55469610
U2 IC70 IC BU4094BF 20718660
U2 S701 ENCODER SWIROTEC16B24204A55V 55134900 MASTER VOLUME
U2 Q701 C-TR DTC114YKA 55133180
U2 Q702 C-TR DTC114YKA 55133180
U2 Q703 C-TR DTC114YKA 55133180
U2 Q704 C-TR DTC114YKA 55133180
U2 Q705 C-TR DTC114YKA 55133180
U2 Q706 C-TR DTC114YKA 55133180
U2 Q707 C-TR DTA114YKA 55133190
U2 RM70 RMOTE SENSOR NJL63H380A 55156010
U2 MJ70 PHONES JACK CKX3-6.35-04BK00 55050690 PHONES
U2 P704 SOCKET AS 5PIN400MM 55553940NR
U2 P703 SOCKET AS 5PIN60MM 55315990NR
U2 P701 SOCKET AS 3PIN80MM 55552310NR
U5
U5 POWER SUPPLY PC BOAR
D
U5 REF NO. NAME DESCRIPTION PART NO.
NOTES
U5 C902 CPM C 100N0F+10%250V 55095430
U5 C903 CPM C 100N0F+10%250V 55095430
U5 C904 CPM C 100N0F+10%250V 55095430
U5 C905 CPM C 100N0F+10%250V 55095430
U5 C906 ELECT C 10MI0F+20%71V 55477130
U5 C907 ELECT C 10MI0F+20%71V 55477130
U5 C908 CPM C 100N0F+10%250V 55095430
U5 C909 CPM C 100N0F+10%250V 55095430
U5 C918 ELECT C 2MI2F+20%16V 13039870
U5 C923 ELECT C 470U0F+20%16V 20269140
U5 C927 CPF C 100N0F+10%50V 20266460
U5 C929 ELECT C 100U0F+20%100V 10250330
U5 C930 ELECT C 470U0F+20%25V 20269190
U5 C936 CPF C 100N0F+10%50V 20266460
U5 C939 CPF C 100N0F+10%100V 55126120
U5 C940 CPF C 100N0F+10%100V 55126120
U5 D901 DIODE RBV-2506 55470130
U5 D904 DIODE W2-04F 55179300
U5 D909 DIODE 1N5819 15042270
U5 D914 ZENER D BZX55B30 20475340
U5 D915 ZENER D BZX55B27 20475330
U5 F910 FUSE FUSTIM500MI0A250V 55263020
U5 IC93 IC KIA7805API 55123960
U5 IC95 IC LM2575HVT-ADJ 55470500
U5 L901 COIL 1M2H+20% 55510490
U5 Q901 TR KTC2026Y 21141190
U5 R911 RESISTOR RMOF2K2OHM+5%2W 90576610
U5 R912 RESISTOR RMOF2K2OHM+5%2W 90576610
