2/8 PAGE
U6
U6 MPEG PC BOARD
U6 REF NO. NAME DESCRIPTION PART NO.
NOTES
U6 C101 ELECT C CE100U0F+20%10V 20268940
U6 C103 ELECT C CE100U0F+20%10V 20268940
U6 C106 ELECT C CE22U0F+20%16V 20251930
U6 C10B ELECT C CE10U0F+20%16V 15002130
U6 C10G ELECT C CE10U0F+20%16V 15002130
U6 C10R ELECT C CE10U0F+20%16V 15002130
U6 C115 ELECT C CE100U0F+20%16V 20269020
U6 C117 ELECT C CE100U0F+20%16V 20269020
U6 C11B ELECT C CE10U0F+20%16V 15002130
U6 C11G ELECT C CE10U0F+20%16V 15002130
U6 C11R ELECT C CE10U0F+20%16V 15002130
U6 C122 ELECT C CE100U0F+20%16V 20269020
U6 C124 ELECT C CE100U0F+20%16V 20269020
U6 C12B ELECT C CE1U0F+20%50V 20268840
U6 C12R ELECT C CE1U0F+20%50V 20268840
U6 C130 ELECT C CE100U0F+20%16V 20269020
U6 C13B ELECT C CE100U0F+20%16V 20269020
U6 C13G ELECT C CE100U0F+20%16V 20269020
U6 C13R ELECT C CE100U0F+20%16V 20269020
U6 C13S ELECT C CE100U0F+20%16V 20269020
U6 C13Y ELECT C CE100U0F+20%16V 20269020
U6 C14B ELECT C CE22U0F+20%16V 20251930
U6 C14G ELECT C CE22U0F+20%16V 20251930
U6 C14R ELECT C CE22U0F+20%16V 20251930
U6 C14S ELECT C CE22U0F+20%16V 20251930
U6 C14Y ELECT C CE22U0F+20%16V 20251930
U6 C201 ELECT C CE100U0F+20%10V 20268940
U6 C203 ELECT C CE470U0F+20%6.3V 20268620
U6 C210 ELECT C CE100U0F+20%10V 20268940
U6 C21P ELECT C CE100U0F+20%10V 20268940
U6 C222 ELECT C CE47U0F+20%16V 20267830
U6 C223 ELECT C CE47U0F+20%16V 20267830
U6 C224 ELECT C CE47U0F+20%16V 20267830
U6 C311 ELECT C CE100U0F+20%10V 20268940
U6 C406 ELECT C CE100U0F+20%10V 20268940
U6 C505 ELECT C CE470U0F+20%6.3V 20268620
U6 C601 ELECT C CE47U0F+20%16V 20267830
U6 C603 ELECT C CE10U0F+20%50V 20268880
U6 C606 ELECT C CE10U0F+20%16V 15002130
U6 C608 ELECT C CE100U0F+20%10V 20268940
U6 C614 ELECT C CE330U0F+20%6.3V 20269110
U6 C617 ELECT C CE100U0F+20%10V 20268940
U6 C61L ELECT C CE47U0F+20%16V 20267830
U6 C61R ELECT C CE47U0F+20%16V 20267830
U6 C65L ELECT C CE47U0F+20%16V 20267830
U6 C65R ELECT C CE47U0F+20%16V 20267830
U6 C66L ELECT C CE47U0F+20%16V 20267830
U6 C66R ELECT C CE47U0F+20%16V 20267830
U6 D101 CHIP D 1SS355 20496510
U6 D601 CHIP D 1SS355 20496510
U6 D602 DIODE 1N4148 70436540
U6 D604 CHIP D 1SS355 20496510
U6 IC11 IC PM0026A 55388940
U6 IC12 IC MM1568AJBE 55389040
U6 IC13 IC TL431 15069010
U6 IC14 IC MC74HC74AD 20997870
U6 IC15 IC 74HC86 15178670
U6 IC1P IC KIA7805AP 55491690
U6 IC21 IC STI5519 55130350
U6 IC22 IC M24C02WMN6 20940740
U6 IC31 IC HY57V651620BTC-8125M 55156290
U6 IC41 IC M29W800AT90N1 55136720
U6 IC51 IC M74HCU04M1R 55133310
U6 IC61 IC WM8728 55291470
U6 IC62 IC BA4560F 55128990
U6 L101 CHIP COIL LF-SMD2U2H+10% 55188040
U6 L102 CHIP COIL LF-SMD2U2H+10% 55188040
U6 L202 CHIP COIL LF-SMD2U2H+10% 55188040
U6 L203 CHIP BEAD FCM2012H-102T04 55126670
U6 L204 CHIP BEAD FCM2012H-102T04 55126670
U6 L205 CHIP BEAD FCM2012H-102T04 55126670
U6 L210 CHIP BEAD FCM2012H-102T04 55126670
U6 L501 CHIP BEAD FCM2012H-102T04 55126670
U6 L601 CHIP BEAD FCM2012H-102T04 55126670
U6 L602 CHIP BEAD FCM2012H-102T04 55126670
U6 L603 CHIP COIL LF-SMD2U2H+10% 55188040
U6 L604 CHIP BEAD FCM2012C-121T06 55126710
U6 R415 CHIP BEAD FCM2012H-102T04 55126670
U6 Q101 CHIP TR DTA114YKA 55133190
U6 Q102 CHIP TR DTC114YKA 55133180
U6 Q103 CHIP TR KTC3875Y 20970460
U6 Q10B CHIP TR DTC114YKA 55133180
