F901 or FUSE 8A-T/UL-ST2 ( 1) 252261GR
!
EV
P101 FFC NCFC7-091512 1 2047091512
EV
P2001 FFC NCFC5-071012 1 2045071012
EV
P2800 FFC NCFC5-091012 1 2045091012
EV
P701 FFC NCFC5-232212 1 2045232212
EV
P703 FFC NCFC5-072512 1 2045072512
EV
P8001 FFC NCFC5-211012 1 2045211012
EV
P8002 FFC NCFC5-091512 1 2045091512
EV
P901 AC CORD AS-UC-2 1 253368AYUN
!
EV
P901 or AC CORD AS-UC-2 ( 1) 253368BLTK
!
EV
[TUNER UNIT]
EV
U001
U0010+U0011+U0012+U0013+U0014+U0015+
U0016
BAAF-0614-1D * 1 1B258514-1D N
EV
U0010
Power Amp / Audio Input Terminals PC board
ass'y
BAAF-0614-1D 1 1B2585614-1D
N
EV
U0011 Digital Input Terminals PC board ass'y BADG-0615-1D 1 1B2585615-1D
N
EV
U0012 Thermal Senser PC board ass'y BAETC-0616-1D 1 1B2585616-1D
N
EV
U0013 Spacer PC board ass'y BAETC-0617-1D 1 1B2585617-1D
N
EV
U0014 Terminal PC board ass'y BAETC-0618-1D 1 1B2585618-1D
N
EV
U0015 FFC Fixture PC board ass'y BAETC-0619-1D 1 1B2585619-1D
N
EV
U0016 Power supply PC board ass'y BAETC-0620-1D 1 1B2585620-1D
N
EV
U002 U0020+U0021+U0022+U0023+U0024 BADIS-0654-1C * 1 1B258554-1C N
EV
U0020 Display PC board ass'y BADIS-0654-1C 1 1B2585654-1C
N
EV
U0021 Standby switch PC board ass'y BADIS-0655-1C 1 1B2585655-1C
N
EV
U0022 Video PC board ass'y BAVD-0656-1C 1 1B2585656-1C
N
EV
U0023 HP Jack PC board ass'y BAETC-0658-1C 1 1B2585658-1C
N
EV
U0024 Primary Wiring PC board ass'y BAPS-0659-1C 1 1B2585659-1C
N
EV
U003 U0030 x 2 BAHDM-0678-1C * 1 1B258578-1C N
EV
U0030 HDMI PC board ass'y BAHDM-0678-1C 1 1B2585678-1C
N
EV
U010 TUNER UNIT KST-MW004MS1-S89S 1 240171
PV
HT-R290
PV
PACKING PROCEDURES PARTS LIS
T
PV
PV
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PV
[PACKING]
PV
A601 PAD AS (AS)HTR290 L & R (29092579A) 1 NSP
PV
A601A PAD (L) 1 29092580A
PV
A601B PAD (R) 1 29092581A
