PV
A605 POLY BAG w850 x d650 1 29100245
PV
A606 TAPE (SEROHAN)NITTO NO.29 1 29110149
PV
A608 SHEET --- 1 29095906
PV
A611 TAPE (SEROHAN)NITTO NO.29 1 29110149
PV
A704A LABEL (DES)290BMDC 1 29391482
N
PV
[ACCESSARY]
PV
A672 POLY BAG w250 x d350 1 29100250A
PV
A674 POLY BAG D250 x d300 x W300(t0.04) 1 29100256A
PV
A676 TAPE (SEROHAN)NITTO NO.29 1 29110149
PV
A678 SHEET (PAD) 1 29096131
PV
A801 INS MANUAL En(HTR390) 1 29400598
PV
A802 INS MANUAL U2EnFr(HTP-390) 1 29400629
PV
A811 INS MANUAL En-QSS(AVX290) 1 29400606
N
PV
A816 INS MANUAL FrEs(HTR390) 1 29400601
PV
A826 INST SHEET U11(2010_RIHD) 1 29355782
PV
A835 HANDBILL (UP-A1)US 1 29380155A
PV
A855 REMO CON RC-762M 1 24140762
PV
A858 ANT COIL NMA-3057 1 232140
PV
A859 FM ANT AS Type W 1 292191
PV
A861 BATTERY R6/AA(UM-3) 2 3010506
PV
A861 or BATTERY R6/AA(UM-3) ( 2) 3010054
PV
A861 or BATTERY R6/AA(UM-3) ( 2) 3010194
PV
A885 WRNTY CARD (ONKYO) 1 29365135
HT-R290
U001
PC BOARD PARTS LIS
T
U001
U001
U001 U0010 + U0011 + U0012 + U0013 + U0014 + U0015 + U0016
U001
U0010
Power Amp / Audio Input Terminals PC board BAAF-0614-1D
U001
U0011
Digital Input Terminals PC board BADG-0615-1D
U001
U0012
Thermal Senser PC board BAETC-0616-1D
U001
U0013
Spacer PC board BAETC-0617-1D
U001
U0014
Terminal PC board BAETC-0618-1D
U001
U0015
FFC Fixture PC board BAETC-0619-1D
U001
U0016
Power supply PC board BAETC-0620-1D
U001
U001
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
U001
[SEMI CONDUCTOR]
U001
D131 C-DIODE DA2J10100 1 223303R2 N
