Onkyo HT-R290 - Page 43

21/53 PAGE
U001
[SW TRM]
U001
E6001 RETAINER MET37-0002 1 27142009T
U001
F6901A FUSE HOL NSCT-1P2031 1 25052133T !
U001
F6901B FUSE HOL NSCT-1P2031 1 25052133T !
U001
F6902A FUSE HOL NSCT-1P2031 1 25052133T !
U001
F6902B FUSE HOL NSCT-1P2031 1 25052133T !
U001
JL501A WIRE HOL NSCT-3P874 1 25051087
U001
JL502A WIRE HOL NSCT-5P876 1 25051089
U001
JL503A WIRE HOL NSCT-7P878 1 25051091
U001
JL600A WIRE HOL NSCT-7P898 1 25051111
U001
JL600B WIRE HOL NSCT-7P898 1 25051111
U001
JL603A WIRE HOL NSCT-9P900 1 25051113
U001
JL603B WIRE HOL NSCT-9P900 1 25051113
U001
JL605B SOCKET NSCT-5P97 1 25050269
U001
JL951A WIRE HOL NSCT-5P896 1 25051109
U001
JL951B WIRE HOL NSCT-5P896 1 25051109
U001
JL952A WIRE HOL NSCT-3P894 1 25051107
U001
JL953B WIRE TRAP NPLG-5P588 1 25055626
U001
JL954A WIRE HOL NSCT-9P900 1 25051113
U001
JL954B WIRE HOL NSCT-9P900 1 25051113
U001
P101B SOCKET NSCT-9P2102 1 25052205
U001
P131 PIN JACK NPJ-1PDO554 1 25045772
U001
P4000 ST JACK MSJ-035-22 1 25045887
U001
P4000 or JACK YKB21-5130 ( 1) 25045387
U001
P4002 PIN JACK NPJ-4PDWR690 1 25045922
U001
P4005 PIN JACK NPJ-4PDWWRR624 1 25045845
U001
P4006 PIN JACK NPJ-4PDWWRR624 1 25045845
U001
P6001 TRM NTM-12PDML362 1 25060433
U001
P6001 or TRM NTM-12PDML356 ( 1) 25060427
U001
P6002 TRM NTM-4PDML364 1 25060435
U001
P6900 CRIMP AS CRIMP AS 1 20799162UL
U001
P6901 CRIMP AS CRIMP AS 1 2069925162UL
U001
P6902 CRIMP AS CRIMP AS 1 2069925169UL
U001
P6903 WS CLAMP CB-71683(L=50) 1 260261
U001
P6906 WS CLAMP CB-71683(L=50) 1 260261
U001
P6909 WS CLAMP CB-71683(L=50) 1 260261
U001
P6913 WS CLAMP CB-71683(L=50) 1 260261
U001
P6915 WS CLAMP CB-71683(L=50) 1 260261
U001
P703B SOCKET NSCT-7P2398 1 25052501
